Apex 100 mm / 4 Inch Unigrip Machine Vice (Cast Iron Frame), 710-100
Roll over the image to zoom in
Key Features
- Product Type: Drill Vices
- Weight: 5 kg
- Sizes (mm): 100 mm
- Size (Inches): 4 inch
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹3,094 (Incl. of all taxes)
₹2,622 + ₹472 GST (18%)
MRP was MRP ₹4,034
Save 35%
5 Business Days
1
–
Download Product LeafletNot available
Download Apex CatalogueNot available
Download Apex CatalogueNot available
Highlights
- Small compact and indispensable Vices with steel jaws. On the face of which are grooved horizontal and vertical notches for holding, round, square, thin & irregular work for drilling & light milling.
- Vices are equipped with a convenient unigrip mechanism. The spindle moves inside the hollow handgrip allowing the vice to be used at a location away from the table edge. This feature increases the scope of application of the range of vices.
Please Note that Products may differ eg. color, size from the product Image displayed on the website. Kindly check the specifications provided to make a better purchase decision.
Specifications
| Sizes (mm) | 100 mm |
|---|---|
| Size (Inches) | 4 inch |
| Depth of Jaws (mm) | 25 mm |
| Opening of Jaws (Lower Portion) | 115 mm |
| Opening of Jaws (Upper Portion) | 120 mm |
| Length overall (mm) | 325 mm |
| Height overall (mm) | 55 mm |
| Width overall (mm) | 180 mm |
| Finish | Hammer Tone Mid Grey |
