Baker 25 - 50 mm Dial Snap Gauge (Without Dial Gauge), DS50
Roll over the image to zoom in
Key Features
- Product Type: Snap Gauge
- Range (mm): 25 - 50 mm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹9,047 (Incl. of all taxes)
₹7,667 + ₹1,380 GST (18%)
MRP was MRP ₹9,350
Save 18%
2 Business Days
1
–
Download Product LeafletNot available
Download Baker CatalogueNot available
Download Baker CatalogueNot available
Highlights
- Designed for quick GO/NOT-GO gauging of diameters of cylindrical parts either inprocess or post process
- Measuring spindle and anvil spindle are manufactured out of graded steel
- Spindles are hardened and ground including screw threads
- Carbide ground and lapped tip of measuring faces ensures maximum wear resistance
- For quick entry, chamfer provided on front edges
- Constant measuring force, which is a result of an in-built spring, eliminates user error
- Once the gauge is set to zero with a master, we can measure the size directly
- For easy reading, the indicator can be rotated and locked
- Best suited for inspection of Continuous / Batch production items
- Setting is done with the help of Gauge Blocks / Cylindrical Setting Masters
- Any standard Dial Indicator with ø8 h6 mm holding shank can be fitted easily
- Also used with Electronic probe & digital dial gauge
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Range (mm) | 25 - 50 mm |
|---|
