Bosch 254 mm Wood Circular Saw Blade Expert For Wood (100 Teeth), 2 608 640 910
Roll over the image to zoom in
Key Features
- Product Type: Circular Saw Blades
- Diameter (mm): 254 mm
- Bore (mm): 30 mm
- No. Of Teeth: 100
- Cutting result: Fine Cut
- Bore with reduction ring mm: 25 / 25.4
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹1,104 (Incl. of all taxes)
₹936 + ₹168 GST (18%)
MRP was MRP ₹1,376
Save 32%
1 Business Days
1
–
Download Bosch CatalogueNot available
Highlights
The Optiline Wood Circular Saw Blade delivers precise quality cuts in all types of wood. Its high-quality precision-ground carbide teeth enable clean cuts, while its base blade made of dimensionally stable SK5 hardened steel (> 40 HRC) ensures accuracy. Furthermore, the blade´s expansion slots lower vibration during use, which dampens noise and reduces heat development. Use this saw blade in all types of wood and wooden materials. It is compatible with hand-held, mitre, sliding mitre and table saws.
Depending on the number of teeth, different results can be achieved with all Optiline Wood Circular Saw Blades, which feature ATB (Alternate Top Bevel) tooth geometry: when equipped with a high tooth count, the blade delivers clean cuts, whereas a low number of teeth guarantees solid and efficient cuts.
Optiline Wood Circular Saw Blade delivers precise quality cuts in all types of wood
- High-quality precision-ground carbide teeth enable clean cuts
- Base blade made of dimensionally stable SK5 hardened steel (> 40 HRC) ensures accuracy
- Expansion slots lower vibration during use, which dampens noise and reduces heat development
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Diameter (mm) | 254 mm |
|---|---|
| Diameter (inches) | 10 inch |
| Bore (mm) | 30 mm |
| No. Of Teeth | 100 |
| Application | Wood |
| Tooth shape | ATB |
| Cutting result | Fine Cut |
| Bore with reduction ring mm | 25 / 25.4 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 2.5 / 1.8 |
| Packaging Type | Paper / Cardboard / Corrugated board - Packaging, pocket, with Euro hole |
| Hook angle ° a | 10 |
| Relief angle ° ß | 16 |
