Fluke 40 Mtr Laser Distance Meter, 417D

Shop all Fluke

SKU: ME.NO.DI.00029

Model: Fluke417D

Roll over the image to zoom in


Key Features

  • Product Type: Distance Meter
  • Weight: 95 g
  • Working Range: 40 Mtr
  • Display: 2 line/1 mm/1/32 in
  • Area: Yes
See all product information

ToolBuy Benefits

₹9,468 (Incl. of all taxes)

₹8,024 + ₹1,444 GST (18%)

MRP was MRP ₹11,800

Save 32%



2 Business Days

1

90303100

Download Product LeafletNot available
Download Fluke CatalogueNot available

Highlights

The Fluke 417D is accurate, durable, and easy to use—just point and shoot. The simple design and easy, one-button measurement operation allow you to minimize time spent measuring and maximize the reliability of measurements.


Features:

  • The Fluke 417D laser meter is accurate, durable, and easy to use—just point and shoot
  • Instantly measure up to 40 m (131 ft.) with a 1-button point-and-click
  • Continuous measurement capable: adjusting as you move closer and farther from your target
  • Quickly calculate area (sq feet/meters)
  • 1-meter drop tested and IP54 rated: built to withstand rainy or dusty conditions
  • Great for interior and exterior applications.


Additional Product Features:

  • Large, 2-line illuminated LCD screen.
  • Three different measurement tasks can be completed quickly and easily with one hand.
  • The bright laser is clearly visible, so you can always see your target point even from a hard-to-reach spot or long distance.
  • Designed for both indoor and outdoor applications.
  • Operates with the Fluke durability and quality you expect.
  • Protected by a 3-year warranty.


What's Included In This Package:

  • Fluke 417D Laser Distance Measurer (Meter)
  • Two AAA batteries
  • Users manual (17 languages)
  • Quick reference guide
  • Lanyard

Maximum relative humidity 85 % @ 20°F to 120 °F
(-7 °C to 50 °C)
Safety CAN/CSA-C22.2 No. 61010-1-04, UL Std. No. 61010-1 (2nd Edition), ISA-82.02.01, IEC Standard No. 61010-1:2001, EN60825-1:2007 (Class II)

  • Applies for 100 % target reflectivity (white painted wall), low background illumination, 25 °C (13 °F).
  • Applies for 10 % to 500 % target reflectivity, high background illumination, -10 °C to +50 °C (14 °F to +122 °F).
  • Tolerances apply from 0.05 m to 10 m (0.001 ft to 32.8 ft) with a confidence level of 95 %. The maximum tolerance may deteriorate to 0.1 mm/m (0.003 in/ft) between 10 m to 30 m (32.8 ft to 98.4 ft) and to 0.15 mm/m (0.005 in/ft) for distances above 30 m (98.4 ft).
  • Applies for 100 % target reflectivity, background illumination between 10,000 lux and 30,000 lux.
  • After user calibration. Additional angle related deviation of ± 0.01° per degree up to ± 45° in each quadrant. Applies at room temperature. For the whole operating temperature range the maximum deviation increases by ± 0.1°.

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

Technical specifications for Fluke 40 Mtr Laser Distance Meter, 417D
Working Range40 Mtr
Typical range0.2-40 m/0.6-131 ft
Typical measuring tolerance2.0 mm ± 1.5 mm/± 0.06 in
Maximum measuring tolerance± 3.0 mm/0.12 in
Accuracy up to 10m (+/-)± 2 mm
Display2 line/1 mm/1/32 in
Display illuminationYes
Laser point at distance6/30/60 mm (10/40/100 m)
AreaYes
Units setting (smallest units displayed)0,000m, 0' 00'' 1/32, 0 in 1/32
Auto laser switch off90 sec
Auto power switch off180 sec
Laser classII
Laser type635 nm, <1 mW
Protection classIP54
Battery life (2 x AAA) 1.5 V NEDA 24A/IEC LR03Up to 3,000 measurements
Drop test1 meter
Temperature range: Storage-25 °C to 70 °C (-13 °F to 158 °F)
Temperature range: Operation-10 °C to 50 °C (14 °F to 122 °F)
Calibration cycleNot applicable
EMC61326-1:2006
