Insize 8V/80V Battery Tester, 9657-80
Roll over the image to zoom in
Key Features
- Product Type: Battery Tester
- Weight: 2.8 kg
- Voltage: 8V/80V
- Resistance (Ohm): 3mOhm/ 30mOhm / 300mOhm / 3Ohm / 30Ohm / 300Ohm / 3000Ohm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹1,21,332 (Incl. of all taxes)
₹1,02,824 + ₹18,508 GST (18%)
Out of Stock
15 Business Days
1
–
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Highlights
- 5-inch LCD touch screen display
- AC four-terminal method sampling for more accurate test result
- Simultaneously measure resistance and voltage
- Supports storing data and saving screenshot with a USB flash drive
- High sampling rate and standard multiple communication interfaces suitable for automated testing
Resistance Specification:
| Range | 3 m Ω | 30 m Ω | 300 m Ω | 3 Ω | 30 Ω | 300 Ω | 3000 Ω |
| Max. Display | 3.1000 m Ω | 31.000 m Ω | 310.00 m Ω | 3.1000 Ω | 31.000 Ω | 310.00 Ω | 3200.0 Ω |
| Resolution | 0.1 µ Ω | 1 µ Ω | 10 µ Ω | 100 µ Ω | 1 m Ω | 10 m Ω | 100 m Ω |
| Measurement Current | 100 mA | 100 mA | 10 mA | 1 mA | 100 µA | 10 µA | 1 µA |
| Frequency of Measurement Current | 1 kHz | ||||||
| Accuracy | Slow | ± (0.5%rdg + 10dgt) | ± (0.5%rdg + 5dgt) | ||||
| Medium | ± (0.5%rdg + 15dgt) | ± (0.5%rdg + 10dgt) | |||||
| Fast | ± (0.5%rdg + 20dgt) | ± (0.5%rdg + 10dgt) | |||||
| Temperature Coefficient | ± (0.05%rdg + 1dgt) / °C | ± (0.05%rdg + 0.5dgt) / °C |
Voltage Specification:
| Range | 8V | 80V | 200V / 400V / 800V |
| 10V | 100V | 1000V | |
| Resolution | 10µV | 100µV | 1mV |
| Accuracy | Slow | ± (0.01%rdg+5dgt) | |
| Medium | ± (0.01%rdg+7dgt) | ||
| Fast | ± (0.05%rdg+7dgt) | ||
| Temperature Coefficient | ± (0.001%rdg+0.5dgt) / °C |
Package Content:
- 1x Battery Tester
- 1x Kelvin Test Lead
- 1x RS232 Cable
- 1x HANDLER Connector
Once the Order is Placed, it can not be cancelled & Delivery time will be as per Stock Availiblity & it may take upto 25 days. Training & Installation will be charged extra if required.
Please Note that Products may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Voltage | 8V/80V |
|---|---|
| Resistance (Ohm) | 3mOhm/ 30mOhm / 300mOhm / 3Ohm / 30Ohm / 300Ohm / 3000Ohm |
| Range mode | Auto Range, Manual Range, Nominal Range |
| Calibration | Short circuit clearing for full ranges |
| Test Speed | slow: 4t/s, medium: 8t/s, fast: 20t/s, exfast: 55t/s |
| Comparing Method | Absolute Tolerance, Percentage Tolerance, Direct-reading Comparison |
| Trig | Internal & External |
| Interface | RS232/RS485/USB DEVICE/LAN interface, support SCPI and Modbus agreement |
| Power Supply | AC: 100V - 240V, 50-60Hz |
| Dimensions (L x W x H) | 307 x 265 x 105 mm |
