Insize-Plus Digital Gap Gauge for Android, ISE-DF10

• Data Output
• Real-time measurement: display maximum value, minimum value current measurement value and measurement curve
• Group measurement: target value and upper and lower tolerance can be set, automatic judgement of OK and NG
• The measurement results can be exported as XML or CSV
• Titanium and synthetic diamond coating probes are optional

Specification of Probes (Optional)

• Customizable measuring range: 0.35 - 6 mm
• Effective range: ±0.5 mm
• Accuracy: 0.35 - 2.0 mm (Range), ±0.03 mm (Accuracy) / 0.35 - 6.0 mm (Range), ±0.04 mm (Accuracy)
• Max. customizable length: 500 mm
• Repeatability: 0.02 mm
• Measuring force: <3.5N
• Measuring time: <1s
