Karam 300 mm Universal Extremity Fixation SS Post For Clamping Beam, SA 25SS (300)
No image available
Key Features
- Product Type: Anchor Points
- Weight: 17.8 kg
- Type of Product: Universal Anchor
- Length: 300 mm
- Material: SS Grade 316
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹49,453 (Incl. of all taxes)
₹41,909 + ₹7,544 GST (18%)
MRP was MRP ₹64,476
Save 35%
10 Business Days
1
73269099
Download Product LeafletNot available
Download Karam CatalogueNot available
Download Karam CatalogueNot available
Highlights
Karam Universal extremity fixation SS post for clamping beam flange width 150mm to 220mm, available height-300mm
Features:
- Anchor designed to be fixed to install a horizontal lifeline
- The base have slots to fit on variable size of structure
- Compatible with Universal Extremity Plate; Ref. PN 4000(09) and Intermediate Ref. PN 4000(10)
- Available Lengths: 300mm, 500mm & 750mm
- Compatible with minimum flange width: 150mm
- Compatible with maximum flange width: 220mm
- Minimum Breaking Strength: 15kN
- Conforms to: EN795:2012 TYPE-A, TS16415:2013
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Type of Product | Universal Anchor |
|---|---|
| Length | 300 mm |
| Material | SS Grade 316 |
| Finish | Electro Polished |
| Min Breaking Strength | 15 KN |
| Flange Width | 150 - 220 mm |
| Grade | EN 795:2012 Type A TS 16415:2013 Certified to AS/NZS 5532:2013 |
