Kristeel Screw Cutting Gauge, 1508
Roll over the image to zoom in
Key Features
- Product Type: Other Engineering Gauges
- Range: 14.5, 47.5 , 55 & 60°
- Graduations: 14.5, 47.5 , 55 & 60° Marking
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹98 (Incl. of all taxes)
₹83 + ₹15 GST (18%)
MRP was MRP ₹110
Save 25%
3 Business Days
1
90173010
Download Kristeel Shinwa CatalogueNot available
Highlights
Kristeel Shinwa is a leading global manufacturer of measuring instruments and tools, Photochemical machining, SMT Stencils, Textile Machinery and Real estate. Combined threading tool gauge for ACME 14 1/2° and angular threads 14 1/2°, 55°, 60°.
Uses:
Produced from hardened and polished stainless steel, and is used for checking tool angles while machining threads in metal turning lathes. Whitworth, BSF, BA, Metric, American National and Acme thread angles are clearly etched on the plate for easy recognition. Gauge is packed with printed card of Metric threads drill/tap sizes for instant reference
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Type of Product | Screw Cutting Gauge |
|---|---|
| Range | 14.5, 47.5 , 55 & 60° |
| TPI | 14, 20, 24, 32 Optional 0.5mm |
| Graduations | 14.5, 47.5 , 55 & 60° Marking |
| Length (mm) | 51 mm |
| Width (mm) | 28 mm |
| Thickness (mm) | 1 mm |
| Accuracy (±mm) | 0.5° |
| Type | Rigid |
| Least Count | 14.5° |
| Standard | EEC-II |
| Finish | Polished |
| Material | Stainless Steel |
