Kusam-Meco 0 - 1500μm Digital Coating Thickness Gauge, KM-FN-500A
Roll over the image to zoom in
Key Features
- Product Type: Coating Thickness Meter
- Weight: 84 g
- Measuring Range: 0 to 1500 mm
- Accuracy: Type A: ±(3%+1μm) / Type B: ±(2%+1μm)
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹12,036 (Incl. of all taxes)
₹10,200 + ₹1,836 GST (18%)
MRP was MRP ₹12,750
Save 20%
3 Business Days
1
90318000
Download Product LeafletNot available
Download Kusam-Meco CatalogueNot available
Download Kusam-Meco CatalogueNot available
Highlights
This compact gauge can be used for non-destructive coating thickness measurement of non-magnetic coatings, e.g. paint, enamel, chrome on steel, & insulating coatings, e.g. pain & anodizing coatings on non-ferrous metals. Coating thickness testing for car paint, electroplating, surface technology, pipeline anticorrosion coating, mechanical equipment surface anticorrosion, chemical equipment and quality control.
Package Content:
- Thickness Guage
- User Manual
- Battery
- Carrying Case
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Measuring Range | 0 to 1500 mm |
|---|---|
| Accuracy | Type A: ±(3%+1μm) / Type B: ±(2%+1μm) |
| Resolution | 0μm~99.9μm (0.1μm) 100μm~999μm (1μm) >1000μm (0.01mm) |
| Backlight | Yes |
| Minimum Curvature Radius Convex | 5mm |
| Minimum Curvature Radius Concave | 25mm |
| Minimum Measuring Area | Diameter 20mm |
| Minimum Thickness of Substrate | 0.2mm (Probe F) / 0.05mm (Probe N) |
| Power Supply | 2 x 1.5V AAA battery |
| Operating Temperature | 0~50°C (32 ~ 122°F) |
| Humidity | 20% ~ 90% RH |
| Storage Temperature | -10 ~ 60°C (14 ~ 140°F) |
| Units | μm, mm, mils |
| Standard Compliance | CE ROHS FCC |
| Maximum Measuring Rate | Two Readings Per Second |
| Calibration | Zero Point Calibration |
| Statistics | No. of readings, Mean, Minimum, Maximum |
| Measuring Principle | Magnetic induction (Probe F) / Eddy Currents (Probe N) |
| Dimension | 110 x 53 x 24 mm |
