Makita 1140 W Chain Mortiser, 7104L

Shop all Makita

SKU: PO.CU.CH.00100

Model: 7104L

Roll over the image to zoom in


Key Features

  • Product Type: Chain Mortiser
  • Weight: 17.28 kg
  • Input Power: 1140 W
  • No Load Speed (RPM): 3200
  • Chain Speed: 1000 FPM
See all product information

ToolBuy Benefits

₹1,25,086 (Incl. of all taxes)

₹1,06,005 + ₹19,081 GST (18%)

MRP was MRP ₹1,50,000

Save 29%



30 Business Days

1

Download Product LeafletNot available
Download Makita CatalogueNot available

Highlights

The Makita 7104L Chain Mortiser is engineered with power and accuracy features and is ideal for timber framing and log home building. The 10.5 AMP motor delivers 3,200 RPM to quickly notch or cut holes in the thick wood stock and will cut lap joints up to 5-1/8" in. The razor-sharp chain is engineered for clean and accurate cutting, with a large adjustable vise and knob for increased versatility. It weighs only 38.1 lbs. for increased portability.

Features:

  • Razor-sharp chain for clean, accurate cutting
  • Extremely portable at only 38.1 lbs.
  • Powerful 10.5 AMP motor (3,200 RPM) to quickly notch or cut holes in thick wood stock
  • Cuts lap joints up to 5-1/8"
  • Large adjustable vise and knob for attaching firmly onto logs 3-1/8" to 12-1/8" thick
  • Innovative power tool notches or cuts through holes in thick wood stock quickly, neatly, and accurately
  • Sliding rear clamp adjustable to the desired width with a quick-adjust tension knob
  • Clamp tension lever for a firm hold on the log
  • Plunge depth adjustment in 1/8" increments
  • Cutting line indication plate
  • Adjust the knob for the re-adjusting position of the chain across the log
  • Quick horizontal chain lever for widening holes
  • Chain tension adjustment cover with snap action
  • The durable plastic boot protects twin steel rails
  • Externally accessible carbon brushes for greater serviceability
  • Built-in carrying handle for ease of transportation
  • Ideal for timber framing or log home building.


What's Included in this Package:

Cutter Chain
Sharpening Holder
Wrench & Oil

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

Technical specifications for Makita 1140 W Chain Mortiser, 7104L
Input Power1140 W
Capacity (Max hole width)130 mm (5-1/8")
Capacity (Max hole depth)155 mm (6-1/8")
No Load Speed (RPM)3200
Power supply cord5.0 m (16.4 ft)
Max. Hole Width (longitudinal)5-1/8"
Max. Hole Width (transverse)1-1/4"
Max. Hole Depth6-1/8"
Chain Speed1000 FPM
AMPS10.5
Overall Length20-1/8"
