Metravi 1μHz - 10MHz Digital DDS Function Generator, DDS-1010
Roll over the image to zoom in
Key Features
- Product Type: Function Generators
- Weight: 4.1 kg
- Frequency Range: 1μHz to 10MHz
- Sampling Rate: 125MSa/s
- Power Source: Mains Operated
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹32,497 (Incl. of all taxes)
₹27,540 + ₹4,957 GST (18%)
MRP was MRP ₹40,500
Save 32%
Out of Stock
5 Business Days
1
85432000
Download Product LeafletNot available
Download Metravi CatalogueNot available
Download Metravi CatalogueNot available
Highlights
- Sine wave output of 10MHz, full frequency range resolution is 1μHz
- Square wave/pulse waveform of 5MHz, its rising, falling, and duty cycle time are adjustable
- Uses DDS implementation method, with 125M/s sampling rate and 14bits vertical resolution
- 6-bit high precision frequency counter that is TTL level compatible
- Arbitrary waveform storage of 2048 points, and it can store up to 16 groups of nonvolatile digital arbitrary waveforms
- Abundant modulation types: AM, FM, PM, ASK, FSK, PSK, PWM
- Powerful PC software
- 4.3-inch high resolution TFT liquid crystal display
- Standard configuration interface: USB Device
- Supports internal/external modulation and internal/external/manual trigger
- Supports sweep output
- Easy-to-use multifunctional knob and number keyboard
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Frequency Range | 1μHz to 10MHz |
|---|---|
| Frequency Resolution | 1μHz |
| Display | TFT Color Display |
| No of Channel | Single |
| Interface | USB |
| Sampling Rate | 125MSa/s |
| Vertical Resolution | 14 bits |
| Power Source | Mains Operated |
| Harmonic Distortion | -40dBc, -50dBc, -55dBc |
| Modulation Type | AM, ASK, FM, FSK, PM, PSK, PWM |
| Working Modes | Duration, Modulation, Output Stobe, Scanning |
| Waveform Type | Arbitrary, DC, Noise, Pulse, Ramp, Sine, Square, Triangle |
| Accuracy | within 90 days: ±50ppm, within 1 year: ±100ppm (18°C-28°C) |
| Waveform Record | Store upto 16 groups of nonvolatile digital arbitrary waveform, Stores Arbitrary Waveform upto 2048 points |
