Mitutoyo 25 - 50 mm Digital Screw Thread Micrometer, 326-252-30
Roll over the image to zoom in
Key Features
- Product Type: Screw Thread Micrometer
- Weight: 380 g
- Range (mm): 25 - 50 mm
- Resolution: 0.001 mm
- Accuracy: ±4 μm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹40,684 (Incl. of all taxes)
₹34,478 + ₹6,206 GST (18%)
MRP was MRP ₹45,970
Save 25%
3 Business Days
1
90173010
Download Product LeafletNot available
Download Mitutoyo CatalogueNot available
Download Mitutoyo CatalogueNot available
Highlights
- IP65 water/dust protection
- 60 degree or 55 degree V-anvil and conical spindle (interchangeable) are optional, which are made of high-grade steel, hardened and precision ground.
- With ratchet stop for constant force.
- With SPC output
- Supplied in fitted plastic case
- Non-slip grip finish
Functions:
- 2 x PRESETS
- ABS / INC (INC ZERO)
- Automatic OFF after 20 minutes of non-use
- Locking functions
- Low voltage alarm
- KEEP
Packing Content:
- 1x Digital thread micrometer
- 1x Spanner,
- 1x SR44 battery,
- 1x Without interchangeable tips
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Range (mm) | 25 - 50 mm |
|---|---|
| Resolution | 0.001 mm |
| Accuracy | ±4 μm |
| Force measurement | 5 - 10 N |
| Display | LCD, Character Height 7.5 mm |
| Measuring Spindle | With spindle lock, ø6.35 mm, spindle pitch 0.5 mm |
| Face Measurement | Interchangeable anvil/spindle inserts (optional) |
| Scale | Thimble & sleeve satin chrome finish, ø18 mm |
| Spindle Feed Error | 3 |
| Battery Life | Approx. 2.4 Years |
| Power Supply | 1x Battery SR-44 |
