UNI-T 1750μm Coating Thickness Gauge, UT343A
Roll over the image to zoom in
Key Features
- Product Type: Coating Thickness Meter
- Weight: 111 g
- Measuring Range: 0 ~ 1750μm
- Data Storage: 199 Groups
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹7,222 (Incl. of all taxes)
₹6,120 + ₹1,102 GST (18%)
MRP was MRP ₹7,200
Save 15%
7 Business Days
1
–
Download Product LeafletNot available
Download UNI-T CatalogueNot available
Download UNI-T CatalogueNot available
Highlights
UT343A is used to measure the thickness of the plated and coated sheet on ferrous/non-ferrous, it has the large range up to 1750um, which is widely used in manufacturing industry, metal-processing industry, chemical industry, commodity inspection area, and also able to work steadily in workshop and outdoor.
Features:
- Measurement method: Single/Continuous
- Metal type: Ferrous/non-ferrous
- Max/Min/Avg
- Unit conversion (um/mil)
- Rotatable screen
- LED/Buzzer alarm
- Auto power off
- LCD brightness control
- Low battery indication
Package Content:
- 1x Coating Thickness Gauge
- 2x 1.5V batteries (LR03)
- Ferrous substrate
- Non-ferrous substrate
- Gift box, English manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Measuring Range | 0 ~ 1750μm |
|---|---|
| Accuracy | ±(3%H+1)μm |
| Data Storage | 199 Groups |
| Measurement Method | Single/Continuous |
| Display Type | EBTN Display |
| Product Color | Red & Grey |
| Certificates | RoHS |
| Power Supply | 2x 1.5V Batteries (LR03) |
| Dimensions (mm) | 117 x 53 x 37 mm |
