HiKoki 28mm 850W Rotary Hammer with SDS-Plus, DH28PCY2S9Z

Shop all HiKoki

SKU: PO.HA.RO.00047

Model: DH28PCY2

Roll over the image to zoom in


Key Features

  • Product Type: Rotary Hammer
  • Weight: 3 kg
  • Impact Rate: 0 - 4300 bpm
  • Impact Energy: 3,4 J
  • Speed (RPM): 0 - 1100 rpm
See all product information

ToolBuy Benefits

₹14,454 (Incl. of all taxes)

₹12,249 + ₹2,205 GST (18%)

MRP was MRP ₹20,080

Save 39%



2 Business Days

1

Download Product LeafletNot available
Download HiKoki CatalogueNot available

Highlights

HiKoki DH28PCY 3 Mode Action Rotary Hammer comes with a motor of 850 Watt and a no-load speed of 0 – 1100 rpm. Its 3-mode action includes hammer drilling, hammering only, and drilling only. The User Vibration Protection system (UVP) and shock absorbing handle minimise vibration during no-load operation. The bit angle adjustment function allows users to adjust the angle of the bit depending on the drilling application. Bit change is made quick and easy with the single action bit change.

The variable speed enables users to set the speed of the rotary hammer to suit the various drilling applications. The double-moulded front handle and the no-slip rear handle enhance user comfort and reduce fatigue. The large trigger and lock-on button can be accessed easily by users to provide better control and protection. This HiKoki rotary hammer also comes with forward and reversible action to ensure accuracy and efficiency.

  • High durability hammering mechanism.
  • Faster drilling speed.
  • Low vibration.
  • Large change lever Located on the side of the tool body for easy operation.
  • Simple bit mounting.
  • Soft and easy to grip for comfortable operation.
  • Angle adjustment function.


Features & Benefits:

  • Hammering mechanism features air channel system: Up to 50% more volume of air cushion *1 reduces wear and damage inside cylinder.
  • Ball bearings: Ball bearing seals in grease and holds temperature low to protect melt down of gear cover.
  • New internal pressure control mechanism: Provides smooth airflow in or out of the gear cover to stabilize and ensure hammering action.
  • Rotation only: For drilling in steel and wood etc.(with optional drill chuck and chuck adapter)
  • Rotation & Hammering: For drilling into concrete etc.
  • Hammering Only: (3-mode models only) Chiseling of concrete or groove digging, etc.


Compact Body

The shortened overall length results in better handling.

Ventilation windows

Double ventilation windows (inlets) in labyrinth construction does less harm to the motor by reducing the ingress of dust and debris into the tool.

New Construction for Motor Protection

Labyrinth Ventilation Windows for reducing the ingress of dust and debris into the tool

Large Change Lever

Located on the side of the tool body for easy operation

Angle Adjustment Function

When using a cold chisel or cutter, the angle of the tool tip can be adjusted by setting the change lever as shown on the left.

Easy to insert a bit

One-push Bit Mounting

Lowest Vibration in its Class

A dynamic damper containing a leaf spring and a weight absorbs vibration by resonating with the tool body.

Vibration Value Comparison (approx.)*2

User Vibration Protection (UVP) system that reduces the vibrations from concrete drilling or chiselling with resonance occured by moving a weight in the oppo site direction to the movement of the hammer

Note: Manufacturer reserves the right to change specifications of parts and accessories without notice. Specifications and standard accessories may vary from country to country.

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

Technical specifications for HiKoki 28mm 850W Rotary Hammer with SDS-Plus, DH28PCY2S9Z
Impact Rate0 - 4300 bpm
Impact Energy3,4 J
Speed (RPM)0 - 1100 rpm
Power SourceCorded
Power Input850 W
Mount Type drillSDS-Plus
Number of speeds1
Max. drilling capacity (wood)32 mm
Max. drilling capacity (metal)13 mm
Max. drilling capacity (concrete)28 mm
Max. Drilling (hollow crown)50 mm
ModesHammer drilling, drilling, chiselling
ScrewdriverYes
CapabilitiesReverse, anti-vibration system,electronic speed control
Hammer drilling into concreteVibration emission value ah, HD = 11.2m/s2 Uncertainty K = 1.5 m/s2
Equivalent chiselling valueVibration emission value ah, CHeq = 10.5m/s2 Uncertainty K = 1.5 m/s2
Standard AccessoriesSide Handle, Depth Gauge, Carrying Case
