Kusam-Meco 7 Digits 9999999 Count Microprocessor Multifunction TRMS Power Meter, KM 8100-A

Shop all Kusam-Meco

SKU: ME.EL.PO.00077

Model: KM8100A

Roll over the image to zoom in

Visit Kusam-Meco Store

Key Features

  • Product Type: Power Meter
  • Input Frequency: 45Hz ~ 70Hz
  • Output Response time: < 1 Sec
See all product information

ToolBuy Benefits

₹36,556 (Incl. of all taxes)

₹30,980 + ₹5,576 GST (18%)

MRP was MRP ₹38,725

Save 20%

Out of Stock

3 Business Days

1

90303390

Download Product LeafletNot available
Download Kusam-Meco CatalogueNot available

Highlights

  • Displays 12 parameters simultaneously: 3 V, 3 A, W, Var, WH, VarH, PF, Hz
  • Applicable Standard: DIN IEC 688
  • Suitable for: 1 Dia 2 W; 1 Dia 3 W; 3 Dia 3 W; 3 Dia 4 W systems
  • 10 Years Power - Off Memory for set data
  • With RS-485 Modbus Output
  • Software for Load Analysis (optional).
  • User-friendly programming.
  • Dielectric Strength: AC 2.8KV / Min, Input / Power / Case, DIN IEC 688
  • Impulse: 6 KV 1.2 x 50 µS, ANSI C37.90a / 1983. DIN IEC 1000 4-5, 4-4.


Technical Data:

Input
Input Voltage Range Voltage: 55 ~ 300 V AC, or 300 ~ 600 V AC, 45 ~ 65 Hz P.T. Ratio programmable upto 9999 / KV
Input Voltage Overrange Voltage: 200% Continuous, 300% of rating for 10sec.
Input Frequency 45Hz ~ 70Hz
Input Current Range Current: 110 % for rating. 0 - 1A or 0 - 5A, C.T. Ratio Programmable up to 9999 / 5 A
Input Current Over Range Current: 400% Continuous, 2000% of the rating for 10sec
Input Burden Voltage 0.25 VA / Unit, Current 0.25 VA / Unit, at 50 / 60Hz

Output
DC Current 0 ~ 20mA DC
Load resistance drive output drive 10 VDC maximum
DC Voltage 0 -10 V DC
Load resistance drive Output drive 5mA maximum
Output Protection No Damage even if the output is open or short-circuit
Output Response Time < 1 Sec
Digital Output Load RS485 Output, Isolate Type with
MODBUS RTU mode 4800, 9600, 19200 Baud Rate, User Selectable

Accuracy
V, A, W ± 0.2 % Fs + 2 Counts at 23° C ± 3°C
Var, WH, VarH, PF ± 0.4 % rdg + 2 Count
Hz ± 0.02 % Fs + 1 C at 23° C ± 3° C

Display Range
V, A, W, Var, PF, Hz, 0.56” Super RED LED (4 Digits = 0 ~ 9999 Counts)
PT, CT User Selectable
WH; VarH, 0.36” Super RED LED (7 Digits = 0 ~ 999999 Counts)


Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

Technical specifications for Kusam-Meco 7 Digits 9999999 Count Microprocessor Multifunction TRMS Power Meter, KM 8100-A
Input Frequency45Hz ~ 70Hz
Output Response time< 1 Sec
Stability< 0.2 %/Year
Operating Temperature-10°C ~ +55°C (20 ~ 95% RH Non - Condensed)
Storage Temperature- 40°C ~ +75°C (20 ~ 95% RH Non - Condensed)
Power SupplyAC 85 ~ 265 V & DC 100 ~ 300 V; 24 VDC (Optional)
MountingPanel Flush Mounting
Memory Capacity10 Years Power Off Memory For Set Data
Dimension (LxWxH)144 x 89 x 135 mm
