MetroQ 1μHz - 20 MHz DDS Function Generator with Counter, MTQ 1515
Roll over the image to zoom in
Key Features
- Product Type: Function Generators
- Weight: 1.2 kg
- Wave Frequency Range: 1μHz ~ 20MHz (Sine Wave) / 1μHz ~ 15MHz (Square & Triangle Wave) / 100μHz ~ 6MHz (Pulse Wave) / 1μHz ~ 6MHz (Arbitrary Wave)
- Channel: 2
- Frequency Accuracy: ±20ppm
- Waveform Vertical Resolution: 13 Bits
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹16,166 (Incl. of all taxes)
₹13,700 + ₹2,466 GST (18%)
5 Business Days
1
85432090
Download Product LeafletNot available
Download MetroQ CatalogueNot available
Download MetroQ CatalogueNot available
Highlights
- 2.4-inch 320x240 TFT LCD with clear graphic interface.
- Chinese / English menu available
- The two channels are independent of each other, with phase synchronization function
- Sampling rate: 200MSa/S, vertical resolution: 13 bit and storage depth: 8k 5.
- Basic waveform and 32 arbitrary waveform in-built
- Waveform storage; Supports internal storage of 50 groups of user-defined edited waveform
- Pulse wave output set in edge time
- Internal AM, FM, PM modulation function (External AM, FM, PM modulation matching)
- Internal/external ASK, FSK and PSK modulation function
- Two-channel output, the highest output frequency is 60M
- Output of linear/logarithmic frequency sweep and burst waveform
- Frequency meter of high precision of 100MHz and 32-bit counter
- With USB Device,external analog modulation interface
- Multi-functional arbitrary waveform editing software equipped.
Technical Data:
| Waveform | ||
| Sine wave | Harmonic Suppression | ≥45dBc (<1MHz); ≥40dBc (1MHz ~ 20MHz) |
| Total Harmonic Distortion | <0.8% (20Hz ~ 20kHz, 0dBm) | |
| Square wave | Rise/Fall time | <20ns |
| Overshoot | <5% | |
| Duty cycle range | Frequency < 100 KHZ: 1% ~ 99%; | |
| 100kHz≤ frequency <5MHz: 20% ~ 80% | ||
| 5MHz≤ frequency: 40% ~ 60%(0.1% resolution) | ||
| Pulse wave | Pulse width | Minimum 20ns; 1 ns resolution |
| Edge jumping time | Minimum 20ns | |
| Overshoot | <5% | |
| Shaking | 6ns + 0.1% period cycle | |
| Sawtooth wave | Linearity | ≥98%(0.01Hz ~ 10kHz) |
| Symmetry | 0.0 ~ 100.0%(resolution 0.1%) | |
| Trigger Input | ||
| Signal Range | 2Vpp~20Vpp | |
| Coupling | AC or DC | |
| Pulse Width | >100ns | |
| Reaction Time | <500ns(Burst) / <10µs (Sweep) | |
| Modulation Input | ||
| Impedance | 1M Ohm | |
| Signal Range | ±2.5V (AC+DC) | |
| Amplitude | ||
| Amplitude range | Frequency <10MHz | |
| 2mVpp~20Vpp | ||
| Amplitude resolution | 1mV | |
| Amplitude accuracy | 1% + 2mVpp of set value (1kHz sine wave, 0 offset, >10mVpp) | |
| Amplitude flatness (Relative to 1k sine wave, 1Vpp) | ±0.4dB <10MHz; ±1.0dB ≥10MHz | |
| Output impedance | 50Ω±10% (typical) | |
| Protection | All signal outputs can work within 60 when the load is short-circuited | |
| Offset | ||
| Output range | Output amplitude > 0.1V 2mV < Output amplitude ≤ 0.1V | |
| ±10Vpk, AC + DC / ±0.250Vpk, AC + DC | ||
| Offset resolution | 1mV | |
| Phase | ||
| Phase adjustment range | 0 ~ 359.9° | |
| Phase resolution | 0.1° | |
| External Measurement Function | ||
| Frequency meter function | 1Hz~100MHz (Frequency Measurement) | |
| Gate time: 0.01S~10s continuous adjustment | ||
| Counter function | Counting range: 0 - 4294967295 | |
| Counting method: Manually | ||
| Input signal voltage range | 2Vpp ~ 20Vpp | |
| Coupling | DC or AC | |
| Pulse width measurement | 1ns resolution, maximum measurable 20s | |
| Period measurement | 1ns us resolution, maximum measurable 20s |
Package Content:
- 1x DDS Function Generator with Counter
- 1x Power cable with three cords
- 2x BNC coaxial cable
- 1x USB data line
- 1x Signal straight line
- 1x User Manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Wave Frequency Range | 1μHz ~ 20MHz (Sine Wave) / 1μHz ~ 15MHz (Square & Triangle Wave) / 100μHz ~ 6MHz (Pulse Wave) / 1μHz ~ 6MHz (Arbitrary Wave) |
|---|---|
| Channel | 2 |
| Frequency Resolution | 1μHz |
| Frequency Accuracy | ±20ppm |
| Frequency Stability | ±1ppm / 3hours |
| Waveform Sampling Rate | 200MSa/S |
| Waveform Vertical Resolution | 13 Bits |
| Storage Depth | 8K |
| Output Impedance | 50 ohm ±10% |
| Waveform Type | Sine, Square, Triangular wave, Pulse, Noise, Arbitrary wave (including DC) |
| Wave Length | 8192 Points |
| Supply Voltage | AC 110 ~ 240V, 50 ~ 60Hz |
| Power Consumption | <15W |
| Display Types | 2.4-inch TFT LCD Screen |
| Display Resolution | 320 × 240 Pixel |
| Display Color | 16M Color |
| Environment Temperature Range | 10°C ~ +40°C (Operation) / -10°C ~ +60°C (Non-operation) |
| Humidity Range | Below +35°C: < 90% relative humidity,+B14035°C ~ +40°C: < 60% relative humidity |
| Cooling Methods | Natural Cooling |
| Interface | USB Device |
