Mitutoyo 0 - 1 inch Spherical Anvil Tube Micrometer (Type E), 115-153
Roll over the image to zoom in
Key Features
- Product Type: Tube Micrometer
- Weight: 180 g
- Range (Inches): 0 - 1 inch
- Graduation (inch): 0.0001 inch
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹4,583 (Incl. of all taxes)
₹3,884 + ₹699 GST (18%)
MRP was MRP ₹4,980
Save 22%
3 Business Days
1
90173010
Download Product LeafletNot available
Download Mitutoyo CatalogueNot available
Download Mitutoyo CatalogueNot available
Highlights
A Mitutoyo non-digital tube micrometer equipped with a spherical anvil for making wall thickness measurements on tubes and pipes. A ratchet stop guarantees repeatable measurement.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- Rounded anvil and spindle design for accurate measurement of tubing wall thickness
- Inch-based vernier scale enables precise outside diameter (OD) readings
- Ratchet-stop feature ensures consistent measuring pressure for reliable results
- Durable baked enamel coating protects the frame and enhances longevity
- Carbide-tipped spindle and anvil surfaces deliver excellent resistance to wear
Package Content:
- Tube Micrometer
- Spanner
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Range (Inches) | 0 - 1 inch |
|---|---|
| Graduation (inch) | 0.0001 inch |
| Max. Permissible Error (JPME) | ±0.00015 inch |
| Diameter (inch) | Ø0.40 inch |
| Measuring Force | 5 - 10 |
| Flatness | 0.000024 inch |
| Measuring Spindle | With Spindle Lock, ø6.35 mm, Spindle Pitch 0.5 mm |
| Scale Finishing | Thimble & Sleeve Satin Chrome Finish, ø18 mm |
