Mitutoyo 0 - 200 mm Absolute Digital Height Gauge With Linear Encoder, 570-227
Roll over the image to zoom in
Key Features
- Product Type: Height Gauge
- Weight: 1.3 kg
- Range (mm): 0 - 200 mm
- Accuracy: ±0.03 mm
- Resolution: 0.01 mm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹39,109 (Incl. of all taxes)
₹33,143 + ₹5,966 GST (18%)
MRP was MRP ₹44,190
Save 25%
7 Business Days
1
90318000
Download Product LeafletNot available
Download Mitutoyo CatalogueNot available
Download Mitutoyo CatalogueNot available
Highlights
Built-in ABSOLUTE linear encoder This encoder eliminates the necessity of setting the reference point at every poweron. It has improved reliability because no over-speed error will occur.
Features:
- Its built-in ABSOLUTE linear encoder means you don‘t have to set the reference point at every power-on, improving reliability as over-speed errors cannot occur.
- Fine-adjustment gives you precise positioning.
- A carbide-tipped scriber is provided.
- With SPC data output.
Functions:
- ABS / INC (INC ZERO)
- DATA (output with cable) / HOLD (display value)
- Low voltage alarm
- ON/OFF
- ORIGIN (ABS-Zero)
- PRESET
- ±SWITCHING
Package Content:
- Digital ABS Height Gauge
- Carbide tipped scriber
- Scriber clamp
- SR44 battery
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Type of Product | Digimatic Height Gauge |
|---|---|
| Range (mm) | 0 - 200 mm |
| Accuracy | ±0.03 mm |
| Resolution | 0.01 mm |
| Display | LCD (6-digit) |
| Fine Adjustment | 4 mm |
| Max. Permissible Error | ±0.03 mm (E MPE & J MPE) |
| Max. Response Speed | Unlimited |
| Power Supply | 1x Battery (SR-44) |
| Battery Life | Approx. 5000 Hours |
| Scale | ABSOLUTE Electrostatic Linear Encoder |
