Mitutoyo 25 - 55 mm Absolute Digital Blade Micrometer (Quickmike Type), 422-412-20
Roll over the image to zoom in
Key Features
- Product Type: Blade Micrometers
- Weight: 490 g
- Range (mm): 25 - 55 mm
- Resolution: 0.001 mm
- Accuracy: ±3μm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹52,632 (Incl. of all taxes)
₹44,603 + ₹8,029 GST (18%)
MRP was MRP ₹59,470
Save 25%
3 Business Days
1
–
Download Product LeafletNot available
Download Mitutoyo CatalogueNot available
Download Mitutoyo CatalogueNot available
Highlights
- Blade-shaped anvil and spindle for measuring the groove diameter of shafts, keyways and other hard-to reach features
- Non-rotating spindle
- Fast spindle feed of 10 mm/revolution
- With ratchet stop for constant force
- Non-slip grip finish
- Supplied in fitted plastic case
Functions:
- ABS / INC (INC ZERO)
- HOLD
- Low voltage alarm
- ON/OFF
- ORIGIN
Package Content:
- 1x Digital Blade Micrometer
- 1x Setting Standard
- 1x SR44 battery
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Range (mm) | 25 - 55 mm |
|---|---|
| Resolution | 0.001 mm |
| Accuracy | ±3μm |
| Remark | Type A |
| Blade Size (mm) | 0.75 mm |
| Display | LCD (Character Height 7.5 mm) |
| Measuring Face | Carbide-tipped or Hardened Steel Spindle & Anvil |
| Measuring Force | 3 - 8 N |
| Measuring Spindle | With Spindle Lock, Ø6.35 mm, Spindle Pitch 0.5 mm |
| Parallelism | 3 μm |
| Scale | Thimble & Sleeve Satin Chrome Finish, Ø18 mm |
| IP Rating | IP65 |
| Power Supply | 1x Battery SR-44 |
| Battery Life | Approx. 5 Years |
