UNI-T 4 to 90° Digital Angle Meter, LM320D

Shop all UNI-T

SKU: ME.NO.DI.00082

Model: LM320D

Roll over the image to zoom in


Key Features

See all product information

ToolBuy Benefits

₹2,006 (Incl. of all taxes)

₹1,700 + ₹306 GST (18%)

MRP was MRP ₹2,000

Save 15%



7 Business Days

1

Download Product LeafletNot available
Download UNI-T CatalogueNot available

Highlights

The new LM320D is a lightweight and portable angle meter with a durable aluminum alloy frame. It features a high-definition color display with automatic screen rotation, supporting a full 4×90° measurement range. The device provides real-time tilt angle data and is equipped with a magnetic base for easy and stable positioning. It is widely used in engineering, construction, and mechanical installation fields.


Features:

  • Aluminum alloy frame, lightweight & portable
  • 4×90° angle measurement
  • Relative/absolute measurement modes
  • Multiple unit options: mm/m, in/ft, %, °
  • Rechargeable 1000 mAh lithium battery
  • LED-backlit rotatable screen
  • Equipped with magnetic bases


Package Content:

  • 1x Angle Meter
  • 1x 1000mAh Lithium Battery
  • 1x Type-C Cable
  • 1x Gift Box
  • 1x User Manual

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

Technical specifications for UNI-T 4 to 90° Digital Angle Meter, LM320D
Rotation Range4° - 90°
Resolution±0.05°
Angle Accuracy & Repeatability±0.2°
Unit°; %; mm/m; in/ft.
Magnetic BaseTwo-sided Magnetic (Bottom & rear)
MaterialAl-alloy frame +ABS
Power Supply1000 mAh Lithium Battery
Working Temperature0°C ~ +50°C
Battery Life14h
Dimensions (mm)83.5 x 70 x 35.5 mm
CertificationsCE, RoHS
LanguageEnglish
