UNI-T 4 to 90° Digital Angle Meter with Three Laser, LM320F
Roll over the image to zoom in
Key Features
- Product Type: Digital Angle Meter
- Weight: 180 g
- Rotation Range: 4° - 90°
- Resolution: ±0.05°
- Laser Lines: 3 Lines
- Laser Accuracy: ±3mm / 5m
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹3,410 (Incl. of all taxes)
₹2,890 + ₹520 GST (18%)
MRP was MRP ₹3,400
Save 15%
7 Business Days
1
–
Download Product LeafletNot available
Download UNI-T CatalogueNot available
Download UNI-T CatalogueNot available
Highlights
The new LM320E is a lightweight and portable angle meter with a durable aluminum alloy frame. It features a high-definition color display with automatic screen rotation, supporting a full 4×90° measurement range. The device provides real-time tilt angle data and is equipped with a magnetic base for easy and stable positioning. It is widely used in engineering, construction, and mechanical installation fields.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- Aluminum alloy frame, lightweight & portable
- 4×90° angle measurement
- Relative/absolute measurement modes
- Multiple unit options: mm/m, in/ft, %, °
- Rechargeable 1000 mAh lithium battery
- LED-backlit rotatable screen
- Equipped with magnetic bases
- Laser indication
- Angle Hold
- Auto Power Off
Package Content:
- 1x Angle Meter
- 1x 1000mAh Lithium Battery
- 1x Type-C Cable
- 1x Gift Box
- 1x User Manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Rotation Range | 4° - 90° |
|---|---|
| Resolution | ±0.05° |
| Angle Accuracy & Repeatability | ±0.2° |
| Laser Lines | 3 Lines |
| Laser Accuracy | ±3mm / 5m |
| Laser Class | 2 |
| Laser Type | 630 - 670nm, <1mW |
| Magnetic Base | Four-sided Magnetic (Bottom, Rear, Left & Right) |
| Unit | °; %; mm/m; in/ft. |
| Material | Al-alloy frame +ABS |
| Power Supply | 1000 mAh Lithium Battery |
| Working Temperature | 0°C ~ +50°C |
| Battery Life | 6h |
| Dimensions (mm) | 83.5 x 70 x 35.5 mm |
| Certifications | CE, RoHS |
| Language | English |
