Insize 0°C - 650°C Infrared Thermal Imaging Camera, 0231-IC650
Roll over the image to zoom in
Key Features
- Product Type: Thermal Imaging Camera
- Weight: 1.15 kg
- Infrared Resolution: 256x192@12um
- Super Resolution: Upgrade to 512 x 384
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹2,32,659 (Incl. of all taxes)
₹1,97,169 + ₹35,490 GST (18%)
Out of Stock
15 Business Days
1
–
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Highlights
- Suitable for electric power, metallurgy, petrochemical, scientific research and teaching, manufacturing, rail transit, building testing, electronic equipment overhaul, mechanical equipment maintenance, etc.
- Four image presentation: IR, VIS, MIF, PIP
- Real-time image can be photographed and video recorded
- Software is included: image browsing, image parameter editing, infrared image analysis, batch report generation, video editing, etc.
- WIFI real-time sharing, one-click connection to mobile device
Technical Data:
| Measurement and analysis | Measurement range | support auto-switching: -40°C~150°C, 0°C-650°C |
| Measurement accuracy | ±2°C or ±2%, whichever is greater | |
| Analyzed target | spotx5, linex5, areax5 | |
| Tracking/alarm |
|
|
| Temperature measuring parameter | emissivity, reflected temperature, target distance, humidity, atmospheric, transmittance, optical transmittance, dew point | |
| Other | isothermals. smart stroke. intelligently calculate the area | |
| Image Display | Display Screen | 4.3", 800x480 pixel touchscreen LCD |
| Digital Camera | 5 MP | |
| Image Code | IR, VIS, MIF, PIP | |
| Image Adjustment | level span mode: automatic, semi-automatic, manual | |
| Color Palettes | white hot, iron red, arctic, rainbow 2, hot iron, rainbow 1, fulgurite, medical, tint, black hot, blue hot, sepia, green hot, ice and fire, amber, customized | |
| Function | Recording Function | Photo & Video (infrared & visible light) |
| Cloud Service | Available | |
| Other | Customized physical button, Intelligent diagnosis, OTA update | |
| Storage & Transmission | Storage | local storage (64GB) and external 64GB SD |
| Image Storage | JPG with temperature information | |
| Video Storage | MP4 (without temperature information), Can be used to record audio synchronously; Irgd (with temperature information), up to 30 Hz for temperature analysis | |
| External Interface | Type-C, SD Card Slot | |
| WiFi | can be connected to the mobile terminal for image and real-time video transmission | |
| Bluetooth | bluetooth 5.0, support image transmission (only for Android) | |
| Power System | Battery Type | Lithium-ion rechargeable battery, working time>5 hours |
| Charging Mode | Type-C charging; PC/portable charger; capable of charging while using | |
| Charging Time | 90% of full charge in 2.5 hours | |
| Environmental Parameter | Operating Temperature | -20°C ~ 50°C |
| Storage Temperature | -40°C ~ 60°D | |
| Protection | IP54, 2-meter drop test | |
| Certification | CE, FCC, ROHS | |
| Physical Parameter | Hardware | illuminator, microphone, speaker, electronic compass, GPS |
Standard Delivery:
- 1x Main Unit
- 1x 64GB SD Card
- 2x Lithium-ion Battery
- 1x Desktop Charger
- 1x Power Adapter
- 1x Software
"Once the Order is Placed, it can not be cancelled & Delivery time will be as per Stock Availiblity & it may take upto 25 days. Training & Installation will be charged extra if required."
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Detector Type | Unrefrigerated vanadium oxide/7.5um ~ 14um |
|---|---|
| Infrared Resolution | 256x192@12um |
| Super Resolution | Upgrade to 512 x 384 |
| Thermal Sensitivity/NETD | <45mK |
| Infrared Frame Rate | 30Hz/9Hz |
| Focal Length | 10.5 mm |
| Field of View | 25° x 19° |
| Spatial Resolution (IFOV) | 1.7 mrad |
| Minimum Object Distance | 0.1m |
| Distance to Spot Size (D:S) | 588:1 |
| Focusing Mode | Manual / Automatic / Continuous Autofocus |
| Digital Zoom | 1.1x - 8x |
| Shot Recognition | Auto |
| Laser Ranging | 0.1m ~ 40m (Indication/Ranging) |
| Dimension (mm) | 292 x 125 x 125 mm |
