Insize 50X - 500X Metallurgical Microscope, 5110-M900
Roll over the image to zoom in
Key Features
- Product Type: Zoom Stereo Microscope
- Weight: 25 kg
- Optical Magnification: 50X - 500X (up to 1000X with optional 100X Objective)
- Digital Magnification: 100X - 1000X (on 21.5" Monitor), up to 2000X with Optional 100X Objective
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹3,60,724 (Incl. of all taxes)
₹3,05,698 + ₹55,026 GST (18%)
MRP was MRP ₹4,24,581
Save 28%
3 Business Days
1
–
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Highlights
- Infinite chromatic aberration correction optical system
- Three way observation tube with infinite hinge
- Translucent and reflective frame, front low-hand position coarse and fine coaxial focus adjustment mechanism, with adjustment elastic device to prevent sliding and random upper limit device
- With brightness memory function
| Objective(infinite long working distance semi-complex achromatic) (Bright Field Objectives) | Working Distance | Numerical Aperture |
| 5X | 13.5 mm | 0.15 |
| 10X | 10.3 mm | 0.30 |
| 20X | 3.0 mm | 0.45 |
| 50X | 2.5 mm | 0.70 |
Package Content:
- 1x Metallurgical Microscope
- 1x Anti-dust Cover
- 1x 0.5X Camera Adapter
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Optical Magnification | 50X - 500X (up to 1000X with optional 100X Objective) |
|---|---|
| Digital Magnification | 100X - 1000X (on 21.5" Monitor), up to 2000X with Optional 100X Objective |
| Stage | Double Layer (Glass Workbench Size: 101 x 101 mm, Travel: 75 x 50 mm) |
| Condenser | Roll-out achromatic condenser (Numerical aperture 0.9) |
| Illumination | 10W Adjustable LED, Transmitted & Reflected |
| Observation Tube | Inverse Image, 50 - 75 mm (Distance Adjustment), Trinocular=100:0 (Two Grade Spectral Ratio Binocular) |
| Diopter Adjusment | ±5 Diopter (Two Eyepieces) |
| Power Supply | Power Adapter |
| Dimension (L X W X H) | 255 x 510 x 530 mm |
| Eyepiece | High eve point large field SWH10X-H (view field: Ø23mm. adjustable visibility) |
