Kusam-Meco 1μHz - 25mHz Arbitrary Waveform Generator, KM 3022B
Roll over the image to zoom in
Key Features
- Product Type: Function Generators
- Weight: 3 kg
- Frequency Range: 1μHz - 25mHz
- Sampling Rate: 250MSa/s
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹28,886 (Incl. of all taxes)
₹24,480 + ₹4,406 GST (18%)
MRP was MRP ₹30,600
Save 20%
7 Business Days
1
90303390
Download Product LeafletNot available
Download Kusam-Meco CatalogueNot available
Download Kusam-Meco CatalogueNot available
Highlights
- Frequency Range: 25 MHZ (sine wave frequency) / 15 MHz (square wave frequency)
- Frequency sweep and burst capability.
- Built-in function generator includes: sine, square, triangle, pulse, noise, harmonic.
- Arbitrary waveform generator with 2M waveform length, 16-bit resolution
- Built-in more than 160 arbitrary waveforms, including exponential rise, exponential fall, ECG, gauss, haversine, Lorentz, dual-tone, DC etc.
- Support AM, DSB-AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3FSK, 4FSK, OSK and PWM modulations.
- Built-in high-order harmonic generator (at most 16-order harmonics).
- Abundant I/O: waveform output, sync signal output, modulation input, 10MHz external time base input/output, and trigger input/output
- Waveform creation PC software included.
- USB remote interfaces.
- SCPI Compatibility for easy instrument programming
Technical Data:
| Waveforms | |
| Standard Waveforms | Sine, Square, Ramp, Pulse, Noise, Harmonic, DC |
| Arbitrary Waveforms | More than 160 kinds, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Haver Sine, Lorentz, Dual-Tone etc |
| Frequency | |
| Sine | 1µHz to 25MHz |
| Square | 1µHz to 15MHz |
| Pulse | 1µHz to 15MHz |
| Ramp | 1µHz to 2MHz |
| Harmonic | 1µHz to 10MHz |
| Noise (-3dB) | 100 MHZ bandwidth |
| Arbitrary | 1µHz to 15MHz |
| Resolution | 1µHz |
| Accuracy | ±1ppm, 18 to 28°C |
| Square | |
| Rise/Fall time | Typical (1kHz, 1Vpp) ≤9ns |
| Overshoot | Typical (100kHz, 1Vpp) ≤5% |
| Duty Cycle | 0.001% to 99.999% Range varies with frequency |
| Non-symmetry | 1% of the period + 4ns |
| Ramp | |
| Linearity | ≤1% of peak output (typical, 1kHz, 1Vpp, symmetry 100%) |
| Symmetry | 0% to 100% |
| Pulse | |
| Period | 67ns to 1Ms |
| Pulse | ≥16ns |
| Duty Cycle | 0.001%~99.999%, Range varies with frequency |
| Rise/Fall time | ≥9ns |
| Overshoot | Typical (1kHz, 1Vpp) ≤5% |
Packages Content:
- 1x Waveform Generator
- 1x BNC to BNC Cable
- 2x Test Leads
- 1x Power Cord
- 1x USB cable
- 1x Software CD
- 1x User Manual
- Fuse (T, 0.5A, 250V, 5 x 20mm)
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Frequency Range | 1μHz - 25mHz |
|---|---|
| Sampling Rate | 250MSa/s |
| Channel | 2 |
| Memory Depth | 2M |
| Max. Frequency | 25M |
| Voltage Resolution | 16 Bit |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -20°C to 60°C |
