Mastech 2000 Count / 1000A AC Digital Clamp Meter with Frequency, M266F
Roll over the image to zoom in
Key Features
- Product Type: Clamp Meters
- Display Count: 2000
- AC current: 200A to 1000A
- Frequency: 2 kHz
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹1,820 (Incl. of all taxes)
₹1,542 + ₹278 GST (18%)
MRP was MRP ₹1,880
Save 18%
7 Business Days
1
–
Download Mastech CatalogueNot available
Highlights
Features:
- Multifunctional Measurement: DC/AC voltage, AC current, resistance, frequency, and insulation test.
- Data Hold: Freeze measurements for easy recording.
- Safety Certified: CAT II 1000V, CAT III 600V ratings for secure operation.
- Additional Features: Includes diode test, continuity buzzer, and low battery display.
- Comprehensive Measurement: Handles a wide range of electrical parameters including insulation resistance.
- Safety Certified: Having safety ratings and certification for safe operation.
- Portability: Compact and lightweight, easy to carry for on-the-go tasks.
Applications:
- Electrical troubleshooting
- Circuit testing
- Home and Office
- Industrial Use
Why Choose MASTECH M266?
The MASTECH M266F provides a reliable and versatile solution for AC measurements. With essential features like insulation testing, safety certifications, and a large jaw opening, it’s the ideal choice for professionals and DIY enthusiasts alike.
Technical Data:
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
2V/20V/200V |
1mV/10mV/0.1V |
±(0.5%+3) |
|
1000V |
1V |
±(0.8%+3) |
|
|
AC Voltage |
200V |
0.1V |
±(1.0%+5) |
|
750V |
1V |
±(1.2%+5) |
|
|
AC Current |
200A |
0.1A |
±(2.5%+5) |
|
1000A |
1A |
±(3.0%+10) |
|
|
Resistance |
200Ω |
0.1Ω |
±(1.0%+5) |
|
2kΩ |
1Ω |
±(1.0%+8) |
|
|
20kΩ |
10Ω |
±(1.0%+8) |
|
|
200kΩ |
0.1kΩ |
±(1.0%+8) |
|
|
2MΩ |
1kΩ |
±(1.0%+8) |
|
|
Frequency |
2kHz |
1Hz |
±(2.0%+5) |
|
Insulation Test |
20MΩ |
10kΩ |
±(2.0%+2) |
|
2000MΩ (Note<500M) |
1MΩ |
±(4.0%+2) |
|
|
2000MΩ (Note>500MΩ) |
1MΩ |
±(5.0%+2) |
Functions:
 |
AC Voltage |
 |
AC Current |
 |
DC Voltage |
 |
Resistance |
 |
Frequency |
 |
Diode |
 |
Continuity |
 |
Data Hold |
Package Content:
- Clamp Meter
- Test Leads
- Battery
- User's manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Display Count | 2000 |
|---|---|
| Voltage | 2V to 1000V (DC) / 200V to 750V (AC) |
| AC current | 200A to 1000A |
| Resistance | 200 Ohm to 20M Ohm |
| Frequency | 2 kHz |
| Jaw Opening | Ø50 mm / 2 inch |
| Insulation Test | 20MOhm to 2000MOhm |
| Continuity Buzzer | <100 Ohm |
| Safety Rating | CAT III 600V, CAT II 1000V |
| Continuity | Yes |
| Data Hold | Yes |
| Peak Measurement | Yes |
| Certificate | RoHS, CE, ETL |
| Power Supply | 1x 9V Battery (6F22) |
| Dimensions | 235 x 96 x 46 mm (9.25 x 3.8 x 1.8 inch) |
