Meco 3-3/4 Digit / 4000 Count 600A AC TRMS Autoranging Digital Clamp Meter With Temperature & Frequency, 90+
Roll over the image to zoom in
Key Features
- Product Type: Clamp Meters
- Weight: 190 g
- Opening Jaw: 30 mm
- AC Voltage (V): 4V / 40V / 400V / 600V
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹1,922 (Incl. of all taxes)
₹1,629 + ₹293 GST (18%)
MRP was MRP ₹1,917
Save 15%
3 Business Days
1
90303390
Download Product LeafletNot available
Download Meco CatalogueNot available
Download Meco CatalogueNot available
Highlights
Digital Clam Meter: 3 ¾ 4000 Count 600A AC TRMS Autoranging Digital Clamp Meter with K Type Thermocouple, Temperature, NCV (LED, Buzzer & EF Strength), Backlight, Torch Light, Diode Test, Data Hold, Capacitance and APO functions.
Features & Benefits:
- 3¾ Digits
- 4000 Counts
- TRMS
- Auto Ranging
- AC Current upto 600A
- AC Voltage upto 600V
- DC Voltage upto 600V
- Temperature
- Capacitance upto 4mF
- Frequency upto 4KHz
- Resistance upto 40MΩ
- Audible Continuity
- Diode Test
- Data Hold
- Backlight Display
- Torchlight for Clamp
- NCV (LED, Buzzer & EF Strength)
- Auto Power Off
- Low Battery Indication
- Jaw Opening : Cable Dia. 30mm (max.)
Accessories
- Test Leads x 1 Pair
- 1.5V 'AAA' Battery x 2 Pcs
- Instruction Manual x 1 Pc
- K Type Thermocouple (upto 260° C) x 1 Pair
- Carrying Case x 1 Pc
Specifications:
| AC Current (TRMS): 4A, 40A, 400A, 600A (Auto Ranging) Accuracy: ±(2.0%rdg+5dgt) on all ranges except ±(3.0%rdg+5dgt) on 4A AC Response: 40Hz ~ 2KHz Overload: 600A AC max. for 1 min |
| AC Voltage (TRMS): 4V, 40V, 400V, 600V (Auto Ranging) Accuracy: ±(1.2%rdg+5dgt) AC Response: 40Hz ~ 2KHz |
| DC Voltage: 400mV, 4V, 40V, 400V, 600V (Auto Ranging) Accuracy: ±(0.8%rdg+5dgt) |
| Temperature: -20 C to 1000 C / 0 0 -4 F to 1832 F Accuracy: ±(3%rdg+5dgt) |
| Capacitance: 4nF, 40nF, 400nF, 4μF, 40μF, 400μF, 4mF (Auto) Accuracy: ±(3%rdg+5dgt) Note: 4nF for Reference only |
| Frequency: 4Hz ~ 4KHz (Auto Ranging) Accuracy: ±(0.5%rdg+5dgt) |
| Resistance (Auto Ranging): 400, 4k, 40K, 400k , 4M, 40M (ohms) Accuracy: ±(1.2%rdg+5dgt) |
| Low Battery: + and - is indicated |
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Opening Jaw | 30 mm |
|---|---|
| AC Voltage (V) | 4V / 40V / 400V / 600V |
| DC Voltage (V) | 400mV / 4V / 40V / 400V / 600V |
| AC Current (A) | 4A / 40A / 400A / 600A |
| Testing Standard | CAT II 600V |
| Diode Accuracy | 1.0 ± 0.6 mA Approx |
| Dimensions LxWxH | 190 x 71 x 30 mm |
| Power Supply | Two 1.5V 'AAA' Size Battery |
| Battery Life | 200 Hours Typical |
