Metravi 0 – 30V / 0 – 5A Programmable DC Regulated Power Supply (Single Output), PRPS-3005A
Roll over the image to zoom in
Key Features
- Product Type: Power Supply
- Weight: 1.5 kg
- Output Voltage: 0 - 30V
- Output Current: 0 - 5A
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹13,703 (Incl. of all taxes)
₹11,613 + ₹2,090 GST (18%)
MRP was MRP ₹17,078
Save 32%
5 Business Days
1
90308990
Download Metravi CatalogueNot available
Highlights
The Metravi PRPS-3005A Programmable DC Regulated Power Supply features a small body with a high resolution of 10 mV/1 mA. The large 2.8 inch LCD displays Constant Voltage output, Constant Current output, cumulative running time, actual Output Power, Channel Output status, actual Voltage Output and actual Current Output, simultaneously. The stable output, low ripple and low noise, enable high-precision test requirements. The intelligent, temperature-controlled fan cooling reduces noise interference, enabling long-term stable output.
The Metravi PRPS-3005A Programmable DC Regulated Power Supply offers multiple settings to protect your meter and over voltage and over current values are user-settable. The Constant Voltage (CV) & Constant Current (CC) intelligent switching modes effectively protect the circuit. When the actual current exceeds the preset current value, the power supply automatically switches to the CC mode to protect the circuit. The Metravi PRPS-3005A Programmable DC Regulated Power Supply features constant power design and a wide application range, providing flexible configurations of higher voltage and current within the rated power range.
Features:
- Small body for easy portability
- High resolution: 10mV / 1mA
- List waveform editing output, editable 10 groups of timing output function
- Low ripple and noise
- Over Voltage / Over Current protection
- Output Voltage and Current curve monitoring function
- Intelligent temperature control fan cooling
- 2.8-inch TFT LCD multiple display
- USB communication interface
- Supports SCPI
- Cooling: Fan cooling, temperature intelligent speed control
- Communication Port: USB communication, compatible with SCPI communication protocol
The output voltage and current change function, makes them suitable for:
- Phone and laptop repairing
- PCB aging tests
- Battery charging
- Discharging experiments & many more applications
Package Content:
- Power Supply
- Power Cord,
- USB Cable,
- User Manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Type of Product | Programmable DC Power Supply |
|---|---|
| Output Voltage | 0 - 30V |
| Output Current | 0 - 5A |
| Input Voltage | 187 ~ 253 Vac |
| Input Fuse | 250V, F3A |
| Input Frequency | 45 ~ 65Hz |
| Input Current | < 100mA (Full Load) |
| Power | 150W |
| Display Resolution | 240 x 320 Pixels |
| Efficiency | 85% |
| Interface | USB |
| Setting Resolution | 10mV, 1mA |
| Setting Accuracy | <0.1%±10mA / <0.1%±20mV |
| Ripple & Noise | Low ripple & noise |
| Readback Accuracy | <0.1%±10mA / <0.1%±20mV |
| Readback Resolution | 10mV, 1mA |
| Load Regulation Rate | < 30mV |
| Line Regulation Rate | < 20mV |
| Temperature Coefficient of Output / Readback Value | 100ppm/°C(Voltage), 200ppm/°C(Current) |
| Transient Recovery Time (50%~100% rated load) | < 1 ms |
| Communication Port | compatible with SCPI communication protocol, USB communication |
| Protective Function | 0 ~ 31V (OVP) / 0 ~ 5.1A (OCP) |
