Metravi 200A Relay Test Set, RNT-5
Roll over the image to zoom in
Key Features
- Product Type: Power Meter
- Accuracy: 1%
- Fixed AC voltage: 50V & 110V
- Input: 230 Volts, single phase, 50Hz. AC
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹60,661 (Incl. of all taxes)
₹51,408 + ₹9,253 GST (18%)
MRP was MRP ₹75,600
Save 32%
5 Business Days
1
90308200
Download Product LeafletNot available
Download Metravi CatalogueNot available
Download Metravi CatalogueNot available
Highlights
Relay Test Set, with current output upto 200A in various ranges.
Features:
- This is a portable testing kit in one unit, suitable for testing protective relay, over current relay, earth fault relay, protective device, circuit breaker, tripping coils etc.
- The set is designed for both laboratory and field use.
- Current output is continuously variable and the output is taken out through a multi-range C.T. The secondary is connected to an ammeter scaled in 0 to 100%
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Accuracy | 1% |
|---|---|
| Fixed AC voltage | 50V & 110V |
| Input | 230 Volts, single phase, 50Hz. AC |
| Time Measurement | 0-9.999Secs. & 0-99.99Secs. in two ranges |
| AC Voltage Output | Continuously variable 0 -230V AC. Capacity- 460VA(Max) |
| Output | Current Output: 0- 1Amp. At 4/10Volts. / 0- 2Amp. At 4/10 Volts. / 0- 5 Amps. At 4/10 Volts. / 0- 10 Amps. At 4/10 Volts. / 0- 20 Amps.at 4/10 Volts. / 0- 50 Amps. At 4Volts. / 0-100 Amps. At 4 volts. / 0-200 Amps At 4Volts |
