Metravi -20°C - 650°C Handheld Thermal Imager, Pro TI-50

The Metravi PRO TI-50 is a handheld Thermal Imager used for predictive and preventive maintenance, equipment troubleshooting and verification for upto 650°C with 384×288 pixels resolution. Easy to operate, just focus the lens towards the object and the thermal and visual images are displayed on the LCD, and can also be saved to a Micro SD Memory Card.

Images can be transferred to a PC by ejecting the MicroSD Memory Card and connecting it to a PC using the card reader (included) or simply transfer the images and videos to your Smart Phone or Device using the free App. Also features Video recording and playback.  Comes with USB Type C and WiFi interfaces, Touchscreen TFT LCD Display and Auto-Fusion function for ease of use in high density areas.

Features:

• Object Temperature Range: -20° to 150°C (-4° to 302°F) / 0° to 650°C (32° to 1202°F)
• Temperature Accuracy: 2°C (3.6°F) or 2% of reading (Environment temperature 10-35°C; Object temperature >0 C)
• Field of View (FoV)/Minimum Focus Distance: 41.5°x 31.1°/ 0.5m
• Spatial Resolution (IFoV): 1.89 mRad
• Image Frequency: 50Hz
• Focus Free
• Zoom: 1-16x continuous, digital zoom
• Focal Length: 9mm
• Focal Plane Array (FPA)/Spectral Range: Uncooled microbolometer/8-14μm
• IR Resolution: 384×288 Pixels
• Display: 3.5 in. LCD, 640×480 pixels Touchscreen
• Image Modes: Infrared Image, Visual Image, Picture in Picture, Auto-fusion, Zoom
• Colour Palette: IRON, Rainbow, Grey, Grey Inverted, Brown, Blue-Red, Hot-Cold, Feather, Above Alarm, Below Alarm, Zone Alarm, Vision Zone
• Automatic Hot/Cold Detection
• Center Spot, Three manual spots
• Storage Media: 8 GB MicroSD card and 3.4GB internal EMMC
• Data transfer between camera and PC. Live video on camera and PC.
• Video Storage Standard MPEG-4 encode. 640×480 at 30fps, on memory card
• Simultaneous storage of IR and visual images
• Image Storage Format Standard JPEG or HIR files including measurement data, on memory card >6000 pictures
• Image Storage Mode IR/visual images
• Image Analysis Tools
• Interfaces: USB Type C and WiFi
• Rechargeable Li-Ion battery, 4 hours operating time
• Auto Power-off

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
