Metravi 96 x 48 mm / 6 Digits Time Totalizer, TT-300
Roll over the image to zoom in
Key Features
- Product Type: Digital Panel Meters
- Type of Product: Time Totalizer
- Display: 6 Digit LED Display
- Auto Ranging: 9999.99Sec to 999999Hrs
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹3,791 (Incl. of all taxes)
₹3,213 + ₹578 GST (18%)
MRP was MRP ₹4,725
Save 32%
5 Business Days
1
90292090
Download Product LeafletNot available
Download Metravi CatalogueNot available
Download Metravi CatalogueNot available
Highlights
6 Digits LED Display, 96 x 48 mm sq, Auto range from 9999.99 to 999999Hrs.
Features:
- Control Input: Proximity Switches / Contact Clusure (Limit Switch, Relay etc.)
- Reset: Front Reset / Remove Reset / Auto Reset (Programmable)
- Sensor Supply: 12V DC
- Size 96 x 48 mm sq
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Type of Product | Time Totalizer |
|---|---|
| Display | 6 Digit LED Display |
| Auto Ranging | 9999.99Sec to 999999Hrs |
| Fixed Range | Fixed at: 9999.99Sec, 99999.9Sec / Min / Hrs, 99Hr / 59Min / 59Sec, 9999.99Sec / Min, 999999Sec / Min / Hrs (User Selectable) |
| Accuracy | ±0.05% |
| Control Input | Contact Closure (Limit Switch, Relay etc.), Proximity Switches |
| Memory Retention | For up to 10 yrs |
| Reset Function | Auto Reset (Programmable), Front Reset, Remove Reset |
| Power Source | Auxiliary Power Supply: 90V to 270V AC 50/60Hz, Sensor Supply: 12V DC, 30mA max |
