Metravi 3-3/4 Digits / 400 - 40M Ohms Digital LCR Meter With Multimeter, 506
Roll over the image to zoom in
Key Features
- Product Type: LCR Meter
- DC Voltage Range: 400mV to 1000V
- AC Voltage Range: 400mV to 750V
- DC Current Range: 400uA to 20A
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹23,875 (Incl. of all taxes)
₹20,233 + ₹3,642 GST (18%)
MRP was MRP ₹29,754
Save 32%
Out of Stock
5 Business Days
1
90303100
Download Product LeafletNot available
Download Metravi CatalogueNot available
Download Metravi CatalogueNot available
Highlights
3-3/4 Digits, Backlit, LCD Dual Display, T-RMS, RS-232 PC Interface, Internal Memory, Min, Max, Avg, Relative Modes, AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Frequency, Inductance, Duty Cycle, Temperature, dBm, Logic, Diode, Signal Output & Continuity Test.
Features:
- True RMS LCR Multimeter With RS-232C PC interface facility 10 Memory Location. Time Mode with alarm, clock and stop watch. MIN., MAX., AVG. and relative modes. Data Hold and Run Modes, 20A Fused Protection
- Display : 3-3/4 Digits Backlit 3999 Counts
- Dual Extra Large LCD
- DC Voltage : 0 – 400mV/4V/40V/400V/1000V
- Accuracy : ±0.3%
- AC Voltage : 0 – 400mV/4V/40V/400V/750V T-RMS.
- Accuracy : ±1.0%
- DC Current : 0 – 400uA/400mA/20A.
- Accuracy : ±1.0%
- AC Current : 0 – 400uA/400mA/20A T-RMS.
- Accuracy : ±1.5%
- Resistance : 0 – 400/4k/40k/400k/4M/40M.Ohms
- Accuracy : ±0.5%
- Capacitance : 0 – 100uF
- Accuracy : ±3.0%
- Frequency : 0 – 10 kHz/100kHz/1MHz/10MHz
- Accuracy : ±0.01%
- Inductance : 0 – 20/50/100H
- Accuracy : ±3.0%
- Duty Cycle : 0.1% ~ 99.9%
- Accuracy : ±1.2%
- Temperature: -20°C~+1200°C / 0°F~+2000°F
- Accuracy : ±3%
- dBm : -25dBm to + 59dBm
- Accuracy : ±0.5dBm
- Logic Test, Diode Test, Signal Output and Audible Continuity test facility.
- Confirms to UL 1244 AND VDE-0411
What's Included In This Package:
- Carrying case
- Instruction manual
- Test leads
- Battery
- RS-232C PC Interface cable & software
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Display | Backlit LCD |
|---|---|
| Colour | Black |
| PC Interface | RS232C |
| Data Logging | 10 data points |
| DC Voltage Range | 400mV to 1000V |
| AC Voltage Range | 400mV to 750V |
| DC Current Range | 400uA to 20A |
| AC Current Range | 400uA to 20A |
| Resistance Range | 400 to 40M Ohms |
| Capacitance Range | 0 to 100uF |
| Frequency Range | 0 to 10MHz |
| Inductance Range | 0 to 100H |
| Temperature Range | -20°C to 1200°C |
| Duty Cycle Range | 0.1% to 99.9% |
| dBm Range | -25dBm to +59dBm |
| Power Source | Battery Operated |
| DC Voltage Accuracy | ±0.3% |
| DC Voltage Resolution | 0.1mV |
| AC Voltage Accuracy | ±1.0% |
| AC Voltage Resolution | 0.1mV |
| DC Current Accuracy | ±1% |
| DC Current Resolution | 0.1μA to 0.01A |
| AC Current Accuracy | ±1.5% |
| AC Current Resolution | 0.1μA to 0.01A |
| Resistance Accuracy | ±0.5% |
| Resistance Resolution | 0.1 to 100 Ohms |
| Capacitance Accuracy | ±3.0% |
| Capacitance Resolution | 0.01uF |
| Frequency Accuracy | ±0.1% |
| Frequency Resolution | 1Hz to 1kHz |
| Temperature Accuracy | ±3% |
| Temperature Resolution | 1°C |
| Certifications | UL 1244, VDE 0411 |
