Owon 5-1/2 Digit / 1000V Bench Type Digital TRMS Multimeter, CP 05+
Roll over the image to zoom in
Key Features
- Product Type: Clamp Meters
- Weight: 200 g
- Test Range: 1mA - 400A
- Resolution: 1mA
- Bandwidth: DC-200KHz (±3dB)
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹17,610 (Incl. of all taxes)
₹14,924 + ₹2,686 GST (18%)
MRP was MRP ₹18,200
Save 18%
Out of Stock
4 Business Days
1
90309090
Download Product LeafletNot available
Download OWON CatalogueNot available
Download OWON CatalogueNot available
Highlights
- Current Probe ,0 to 4A /40A /400A - AC / DC, Frequency Response 200 KHz.
| AC Current | Range | AC 4A | AC 4 0A | AC 200A | AC 200A - 400A |
| Accuracy | ±2.0%rdg±5-digit | ±3.0%rdg±5-digit | |||
| Sensitivity | 1mV/10mA | 1mV/0.1A | 1mV/1A | ||
| DC Current | Range | DC 4A | DC 40A | DC 200A | DC 200 - 400A |
| Accuracy | ±1.5%rdg±5-digit | ±3.0%rdg±5-digit | |||
| Sensitivity | 1mV/10mA | 1mV/0.1A | 1mV/1A |
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Test Range | 1mA - 400A |
|---|---|
| Resolution | 1mA |
| Auto Zero at Power-on | v |
| Operating Temperature | 0°C to 50°C |
| Jaw Size | 23mm (max) |
| Operating Humidity | 15% to 70% RH |
| Power Supply | 9V 6F22 Battery |
| Bandwidth | DC-200KHz (±3dB) |
| Dimension (W x H x D) | 180 x 30 x 44 (mm) |
| Includes | Soft Bag |
