Amprobe 1000V TRMS Digital Multimeter With Temperature, 34XR-A
Roll over the image to zoom in
Key Features
- Product Type: Multimeter
- Capacitance: 4.000 μF, 40.00 μF, 400.0 μF, 4000 μF
- Temperature: 1832 °F (1000 °C)
- Duty cycle: 0.0 % - 90.0 %
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹25,034 (Incl. of all taxes)
₹21,215 + ₹3,819 GST (18%)
MRP was MRP ₹31,198
Save 32%
3 Business Days
1
9030
Download Product LeafletNot available
Download Amprobe CatalogueNot available
Download Amprobe CatalogueNot available
Highlights
The Amprobe 34XR-A Digital Multimeter, a True-rms digital multimeter with temperature and backlight for contractors and field service technicians.
Features:
- Autoranging; display: 3-3/4 digit LCD, 3999 counts with 41-segment analog bar graph
- Display update rate: 2/sec, nominal
- Operating temperature: 0 °C to 45 °C at < 70 % R.H
- True-rms digital multimeter with temperature and backlight
- Overrange indication
- Auto power off to save battery life
- Min/max, data hold and range lock
- Separate door for easy battery and fuse access
- Magne-Grip™ Holster with magnetic hanging strap
What’s Included In This Package:
- 34XR-A
- Test leads with threaded alligator clips
- 9 V battery (installed)
- Magne-Grip™ Holster with magnetic hanging strap
- Temperature adapter
- Type K thermocouple probe
- Spare fuse
Specifications:
| DC Voltage ranges | 400 mV, 4 V, 40 V, 400 V, 1000 V |
| DC Voltage accuracy | All ranges: ± (0.5 % rdg + 1 dgt) |
| DC Voltage resolution | 100 µV |
| AC Voltage (45 Hz to 2 kHz) True-rms ranges | 400 mV, 4 V, 40 V, 400 V, 750 V |
| AC Voltage (45 Hz to 2 kHz) True-rms accuracy | 400 mV range, 45 to 100 Hz: ± (1.2 % rdg + 8 dgts)
750 V range: 45 to 1 kHz: ± (2.0 % rdg + 8 dgts) All other ranges, 45 to 500 Hz: ± (1.2 % rdg + 8 dgts) All other ranges, 500 to 2 kHz: ± (2.0 % rdg + 8 dgts) |
| AC Voltage (45 Hz to 2 kHz) True-rms resolution | 100 µV |
| DC Current ranges | 400 µA, 4 mA, 40 mA, 300 mA, 10 A |
| DC Current accuracy | 400 µA to 300 mA ranges: ± (1.0 % rdg + 1 dgt)
10 A range: ± (2.0 % rdg + 3 dgts) |
| DC Current resolution | 0.1 µA |
| AC Current (45 Hz to 1 kHz) True-rms ranges | 400 µA, 4 mA, 40 mA, 300 mA, 10 A |
| AC Current (45 Hz to 1 kHz) True-rms accuracy | 400 µA to 300 mA ranges: ± (1.5 % rdg + 8 dgts)
10 A range: ± (2.5 % rdg + 10 dgts) |
| AC Current (45 Hz to 1 kHz) True-rms resolution | 0.1 µA |
| Resistance ranges | 400 mO 4 kmO 40 kmO 400 kmO 4 MmO 40 MmO |
| Resistance accuracy | 400, 4 k, 40 k, 400 k, 4 MmO ranges: ± (1.0 % rdg + 4 dgts)
40 MmO range: ± (2.0 % rdg + 5 dgts) |
| Resistance resolution | 100 mmO |
| Continuity audible indication | < 35 mO |
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| DC Voltage | 400.0 mV, 4.000 V, 40.00 V, 400.0 V, 1000 V |
|---|---|
| AC Voltage | 400.0 mV, 4.000 V, 40.00 V, 400.0 V, 1000 V |
| DC Current | 400.0 μA, 4.000 mA, 40.00 mA, 300.0 mA, 10 A |
| AC Current | 400.0 μA, 4.000 mA, 40.00 mA, 300.0 mA, 10 A |
| Resistance | 400.0 O, 4.000 kO, 40.00 kO, 400.0 kO, 4.000 MO. 40.00 MO |
| Continuity | Yes |
| Diode | Yes |
| Capacitance | 4.000 μF, 40.00 μF, 400.0 μF, 4000 μF |
| Frequency | 4.000 kHz, 40.00 kHz, 400.0 kHz, 1 MHz |
| Temperature | 1832 °F (1000 °C) |
| Duty cycle | 0.0 % - 90.0 % |
