Fluke 1LAC II A 20V - 90V Non-Contact Low Voltage Tester
Roll over the image to zoom in
Key Features
- Product Type: Electrical Testers
- Detector tip style: Round-tip
- Safety Rating: 1000 V, CAT IV
- Batteries: 2 AAA alkaline batteries included
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹5,207 (Incl. of all taxes)
₹4,413 + ₹794 GST (18%)
MRP was MRP ₹6,490
Save 32%
12 Business Days
1
90303900
Download Product LeafletNot available
Download Fluke CatalogueNot available
Download Fluke CatalogueNot available
Highlights
The Pocket-Sized Voltage Detector
The pocket-sized voltage detector. The Fluke 1LAC II Non-Contact Voltage Tester is easy to use – just touch the tip to a terminal strip, outlet, or supply cord. When the tip glows red and the unit beeps, you know there's voltage present.
Electricians, maintenance, service, safety personnel, and homeowners can quickly test for energized circuits in the workplace or at home.
The 1LAC II tester lets you work the way need to in different situations:
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
The pocket-sized voltage detector. The Fluke 1LAC II Non-Contact Voltage Tester is easy to use – just touch the tip to a terminal strip, outlet, or supply cord. When the tip glows red and the unit beeps, you know there's voltage present.
Electricians, maintenance, service, safety personnel, and homeowners can quickly test for energized circuits in the workplace or at home.
Simple To Use, The Way You Want It:
The 1LAC II tester lets you work the way need to in different situations:
- Audible/Silent modes
- On/Off button to help prolong battery life
- CAT IV 1000 V for added protection.
Upon detection of voltage, the tester tip glows red and beeper sounds (if activated). The 1LAC II is backed by a two-year warranty.
Features:
- Non-contact voltage detection from 20 to 90 V AC
- On/off button with continuous self-test helps prolong battery life
- Fast, simple go/no-go voltage detection.
What's Included In This Package:
- Low Voltage Detector 20-90 VA
- Americas Pacific Round-tip
Specifications:
| Operating Principles | Senses the steady-state electrostatic field produced by AC voltage through insulation without requiring contact to the bare conductor. A red glow at the tip and a beeping noise (if not switched OFF) indicates the presence of voltage. |
| Operating Humidity Ranges | 0% to 95% (0°C to 30°C) |
| 0% to 75% (30°C to 40°C) | |
| 0% to 45% (40 to 55°C) | |
| Product does not respond to random electrostatic discharge. |
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Voltage sensing ranges | 20 V to 90 V control circuit model |
|---|---|
| Detector tip style | Round-tip |
| Light source | One high intensity red LED |
| Agency Approvals | c CSA us, CE, C-Tick |
| Safety Rating | 1000 V, CAT IV |
| EMC Compliance | Meets IEC 61326-1:2006 |
| IP Rating | IP 40 |
| Operating Temperature | -10°C to 50°C (-14°F to 122°F) |
| Operating Altitude | 3000 m |
| Cleaning | Clean with damp cloth |
| Batteries | 2 AAA alkaline batteries included |
| Battery Life | Typical battery life of greater than 1 year |
| Warranty Period | Two years |
| Safety Compliance | Meets IEC 61010-1:2001, UL 61010-1 (2nd ed.), CAN/CSA-C22.2 No. 61010-1-04, and ISA-82.02.01 Pollution Degree 2 |
