Motwane 6000 Count TRMS Digital Multimeter With Backlight, M63
Roll over the image to zoom in
Key Features
- Product Type: Multimeter
- Weight: 450 g
- Display Count: 6000 Count
- Operating Temperature: 0°C to 50°C
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹25,075 (Incl. of all taxes)
₹21,250 + ₹3,825 GST (18%)
MRP was MRP ₹25,000
Save 15%
7 Business Days
1
90303100
Download Product LeafletNot available
Download Motwane CatalogueNot available
Download Motwane CatalogueNot available
Highlights
Motwane’s true RMS industrial graded Digital Multimeter M63 is specially designed in our research laboratory with stringent manufacturing standards. It has a wide range of applications in power generation, distribution, and transmission along with steel industries, cement industries, mining, power electronics, heavy engineering industries, defense, and aviation sector. M63 is a versatile and high performance industrial grade multimeter that complies with IEC 61010-1-2010, CE, CAT IV 600V safety ratings, and IP 54 protection safety standards. It provides an excellent noise immunity against disturbances from energized power lines. M63 measures AC/DC voltage and current, resistance, capacitance, electronic and electrical frequency, continuity beeper, diode test (2.85 Volt open circuit voltage), and 6000 counts resolutions
Features:
- 6000 counts LCD display with a pleasant white backlight
- AC/DC current range up to 20A
- Resistance, capacitance, diode & continuity measurement facility
- Selectable frequency & duty cycle measurement
- 60 positions analog bar graph for trend indication
- Highly linear readings
- SELECT, RANGE, HOLD/LIGHT, REL, Hz/DUTY
- MAX/MIN function incorporated
- Safety – CE, CAT IV (600V), IP 54, EN 61326-1 & IEC 61010-1
- Robust, rugged & double mold casing.
- Auto Power OFF: After 15 Min., Ideal sleep mode, consumption is 300uA approx. (Can be cancelled by pushing SELECT key before power on the meter).
- Fuse Protection for ‘mA’ input terminal: 0.75 A/ 0.8 A/ 500V fast blow type ceramic fuse.
- Fuse Protection for 20A input terminal: 20A/ 500V fast blow type ceramic fuse
Application:
- Power Utility
- Industries
- Electrical Contractor
- Telecommunication
- Railway
- Defense
Technical Data:
| DC Voltage (Note: Input Impedance 10M Ohm approx) | ||||
| Range | Resolution | Max. Reading | Accuracy | Overload protection |
| 600mV | 0.1mV | 600.0mV | ±(0.5% + 3) | 1050V DC / AC RMS |
| 6V | 1mV | 6.000V | ||
| 60V | 10mV | 60.00V | ||
| 600V | 100mV | 600.0V | ||
| 1000V | 1V | 1000V | ±(0.8% + 3) | |
| AC Voltage (50-500Hz)Trms (Note Input impedance: 10 M Ohm approx. shunted by 60pF approx) | ||||
| Range | Resolution | Max. Reading | Accuracy | Overload Protection |
| 6V | 1mV | 6.000V | ±(1% + 5) | 1050V DC / AC RMS |
| 60V | 10mV | 60.00V | ||
| 600V | 100mV | 600.0V | ||
| 750V | 1V | 750V | ±(1.2% + 8) | |
| DC’mV’ Range (Input Impedance: ≥1000M Ohm approx.) | ||||
| Range | Resolution | Max. Reading | Accuracy | Overload Protection |
| 60mV | 0.01mV | 60.00mV | ±(0.5% + 3) | 1000V DC / AC rms |
| 600 mV | 0.1mV | 600.0mV | ||
| AC’mV’ Range (50Hz-1KHz) Trms (Input Impedance: ≥1000M Ohm approx.) | ||||
| Range | Resolution | Max. Reading | Accuracy | Overload Protection |
| 60mV | 0.01mV | 60.00mV | ±(1% + 5) | 1000V DC / AC rms |
| 600mV | 0.1mV | 600.0mV | ||
| DC Current Rang (Note: 1.10A for continuous / 2.>10A for 20sec. after 15min. cool down interval) | ||||
| Range | Resolution | Max. Reading | Accuracy | Overload Protection |
| 60 mA | 0.01 mA | 60.00 mA | ±(1% + 5) | 0.75A / 0.8A / 500V DC / AC fuse protection |
| 600 mA | 0.1 mA | 600.0 mA | ||
| 6 A | 1 mA | 6.000 A | 20A / 500V DC / AC fuse protection | |
| 20 A | 10 mA | 20.00 A | ±(1.2% + 5) | |
| AC Current Range (50Hz-500Hz) Trms (Note: 1.10A for continuous / 2.>10A for 20sec. after 15min. cool down interval) | ||||
| Range | Resolution | Max. Reading | Accuracy | Overload Protection |
| 60 mA | 0.01mA | 60.00mA | ±(1.2% + 5) | 0.75A / 0.8A / 500V DC / AC fuse protection |
| 600 mA | 0.1 mA | 600.0mA | ||
| 6A | 1 mA | 6.000 A | 20A / 500V DC / AC fuse protection | |
| 20A | 10mA | 20.00 A | ±(1.5% + 5) |
Resistance Range (Note: Open Circuit Voltage on 600 - 6M Ohm ranges is 0.62V DC approx. / Open Circuit Voltage on 60M Ohm range is 0.31V DC approx)
| Range | Resolution | Max. Reading | Accuracy | Overload protection |
| 600 Ohm | 0.1 Ohm | 600.0 Ohm | ±(0.5% + 3) | 1000V DC/AC rms |
| 6 K Ohm | 1 Ohm | 6.000 Ohm | ±(0.5% + 3) | |
| 60 K Ohm | 10 Ohm | 60.00 KOhm | ±(0.5% + 3) | |
| 600 K Ohm | 100 Ohm | 600.0 KOhm | ±(0.5% + 3) | |
| 6 M Ohm | 1 K Ohm | 6.000 MOhm | ±(1% + 5) | |
| 60 M Ohm | 10 K Ohm | 60.00 MOhm | ±(3% + 5) |
Capacitance Range (Auto Ranging Only) (Note: Setting Time On 4000uf Range Is 40sec. Approx.)
| Range | Resolution | Max. Reading | Accuracy | Overload protection |
| 40 nF | 0.01 nF | 39.99 nF | ±(3.0% + 10) | 1000V DC/AC rms |
| 400 nF | 0.1 nF | 399.9 nF | ±(3.0% + 10) | |
| 4 µF | 1 nF | 3.999 µF | ±(3.0% + 10) | |
| 40 µF | 10 nF | 39.99 µF | ±(3.0% + 10) | |
| 400 µF | 100 nF | 399.0 µF | ±(3.0% + 10) | |
| 4000 µF | 1 µF | 3999 µF | ±(5.0% + 20) |
Diode Test:
| Range | Resolution | Open Circuit Voltage | Test Current |
| 6V | 1mV | ≤2.85 V DC | ≤1mA approx.. |
Continuity Test: (Note: Open Circuit Voltage on continuity range is 0.64VDC approx.)
| Range | Resolution | |
| 600.0 Ohm | 0.1 Ohm | Meter Beeps at 60 Ohm |
Frequency Ranges (Auto Ranging Only)
| Range | Resolution | Max. Reading | Accuracy | Overload protection |
| 10 Hz | 0.001 Hz | 9.999 Hz | ±(0.1% + 3) | 1000V DC/AC rms |
| 100 Hz | 0.01 Hz | 99.99 Hz | ±(0.1% + 3) | |
| 1 kHz | 0.1 HZ | 999.9 Hz | ±(0.1% + 3) | |
| 10 kHz | 1 Hz | 9.999 KHz | ±(0.1% + 3) | |
| 100 kHz | 10 Hz | 99.99 KHz | ±(0.1% + 3) | |
| 1000 kHz | 100 Hz | 999.9 KHz | ±(0.1% + 3) | |
| 10 MHz | 1 kHz | 9.999 MHz | ±(0.1% + 3) |
Duty Cycle Measurement
| Range | Resolution | Accuracy | Overload Protection |
| 0.1%-99.9% | 0.1% | ±(0.5% + 3) | 1000V DC/AC rms |
Package Content:
- Digital Multimeter
- User Manual
- Battery installed
- Fuses
- Carry Bag
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Display Count | 6000 Count |
|---|---|
| Type of Display | LCD Display with White Backlit |
| Display Update Rate | 3 Times Per Second Nominal |
| Operating Temperature | 0°C to 50°C |
| Relative Humidity | 80% RH 5°C to 31°C (50% RH 31°C to 40°C Non Condensing) |
| Storage Temperature | -20°C to 60°C |
| Power Supply | 9V Battery Type 6F22 or Equivalent |
| Power Consumption | 4mA Typical |
| Low Battery Indication | 'LO BAT' is Displayed Below 6.5v Approx |
| Overload Protection (Ohm/ / / / /Hz(%)) | 1000V DC/AC rms |
| Directives for CE Certification | LVD: 2006/95/EC, EMC: 2004/104/EC |
| Measurement Category | CAT IV, 600V Reinforced Insulation |
| Relevant Standard Specification | EN 61010-1:2010, EN61326-1:2006 |
| IP Rating | IP54 (Dust & Water Protection) |
| Dimensions (W x H x D) | 94 X 205 X 36 mm |
