UNI-T 20000 Count Non-Contact Voltage Digital Multimeter, UT39E+
Roll over the image to zoom in
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹3,310 (Incl. of all taxes)
₹2,805 + ₹505 GST (18%)
MRP was MRP ₹3,300
Save 15%
7 Business Days
1
–
Download Product LeafletNot available
Download UNI-T CatalogueNot available
Download UNI-T CatalogueNot available
Highlights
UT39+ series modern digital multimeters are portable devices designed for the electrical industry. They feature overvoltage and overcurrent alarm and high voltage protection, triggered during faulty operation. Designed according to CAT II 1000V/CAT III 600V safety standards.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- 1000V DC voltage measurement
- 750V AC voltage measurement
- 10A DC/AC current measurement
- Resistance/Capacitance
- hFE
- Diode/Continuity test
Applications:
- Voltage measurement
- NCV measurement
- Current measurement
- Capacitance measurement
Package Content:
- 1x Digital Multimeter
- Test leads
- Temperature probe
- English manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Display Count | 20000 |
|---|---|
| Category Ratings | CAT II 1000V, CAT III 600V |
| DC voltage | 200mV / 2V / 20V / 200V / 1000V ±(0.05%+3) |
| AC Voltage | 200mV / 2V / 20V / 200V / 1000V ±(0.5%+10) |
| DC Current | 2000uA / 20mA / 200mA / 2A / 20A ±(0.5%+5) |
| AC Current | 2000uA / 20mA / 200mA / 2A / 20A ±(0.8%+10) |
| Resistance (Ohm) | 200 Ohm / 2k Ohm / 20k Ohm / 2M Ohm / 20M Ohm / 200M Ohm ±(0.3%+2) |
| Capacitance (F) | 2000uF ±(4%+20) |
| Frequency (Hz) | 10Hz ~ 2MHz ±(0.1%+3) |
| Temperature (°C) | - 40°C ~ 1000°C ±(1%+5) |
| Temperature (°F) | -40°F ~ 1832°F ±(1.5%+5) |
| Conductance (nS) | 0.1 ~ 100nS |
| Power | 2x 1.5V Battery (R03) |
| Display Size (mm) | 56.5 x 36 mm |
| Dimension (mm) | 175 x 83 x 53 mm |
