Meco 3-5/6 Digit / 6000 Counts TRMS Autoranging Pocket Size Digital Multimeter, 108P+

Shop all Meco

SKU: ME.EL.MU.00290

Model: 108P+TRMS

Roll over the image to zoom in

Visit Meco Store

Key Features

  • Product Type: Multimeter
  • Weight: 173 g
  • Display Digits: 3-5/6 Digit
  • Display Counts: 6000 Counts
See all product information

ToolBuy Benefits

₹1,607 (Incl. of all taxes)

₹1,362 + ₹245 GST (18%)

MRP was MRP ₹1,602

Save 15%

3 Business Days

1

90303100

Download Product LeafletNot available
Download Meco CatalogueNot available

Highlights

  • TRMS
  • Auto Ranging
  • Duty Cycle
  • Temperature
  • NCV Test
  • LIVE Test
  • Diode Test
  • Audible Continuity
  • Data Hold
  • REL Δ
  • LCD with Backlight
  • Auto Power Off
  • Low Battery Indication


Technical Data:

DC Voltage
  • Range: 60 / 600mV / 6 / 60 / 600 / 1000V
  • Accuracy: ±(0.5% rdg + 3 dgt)
AC Voltage (TRMS)
  • Range: 60 / 600mV / 6 / 60 / 600 / 1000V
  • Accuracy: ±(1.0% rdg + 3 dgt)
  • AC Response: 1Hz ~ 1KHz
DC Current
  • Range: 600 / 6000μA / 60 / 600mA / 6 / 10A
  • Accuracy: ±(0.8% rdg+3 dgt) on all ranges except ±(1.0% rdg+3 dgt) on 6 / 10A
AC Current (TRMS)
  • Range: 600 / 6000μA / 60 / 600mA / 6 / 10A
  • Accuracy: ±(1.0% rdg+3 dgt) on all ranges except ±(1.2% rdg+3 dgt) on 6 / 10A
  • AC Response: 1Hz ~ 1KHz
Resistance
  • Range: 600Ω / 6 / 60 / 600KΩ / 6 / 60MΩ
  • Accuracy: ±(1.0% rdg + 3 dgt) on 600Ω ±(0.5% rdg + 2 dgt) on 6 / 60 / 600kΩ / 6MΩ ± (1.5% rdg + 3 dgt) on 60MΩ
Capacitance
  • Range: 9.999 / 99.99 / 999.9nF / 9.999 / 99.99 / 999.9μF / 9.999mF
  • Accuracy: ±(3.5% rdg + 5 dgt) on all ranges except ± (5.0% rdg + 5 dgt) on 9.999mF ± (5.0% rdg + 20 dgt) on 9.999nF
Frequency
  • Accuracy: ±(0.08% rdg + 2 dgt)
Duty Cycle
  • Accuracy: ±(0.08% rdg + 2 dgt)
Temperature
  • Accuracy: ±(1.0% rdg + 5 dgt) on <400°C / >752°F; ±(1.5% rdg + 15 dgt) on >400°C / >752°F


Package Content:

  • 1x Digital Multimeter
  • 1 Pair x Test Leads
  • 2x 1.5V 'AAA' Battery
  • 1x Instruction Manual x 1 Pc
  • 1x Carrying Case x 1 Pc
  • 1x K Type Thermocouple (upto 260°C)


Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

Technical specifications for Meco 3-5/6 Digit / 6000 Counts TRMS Autoranging Pocket Size Digital Multimeter, 108P+
Display Digits3-5/6 Digit
Display Counts6000 Counts
DC VoltageUpto 1000V
AC VoltageUpto 750V
DC CurrentUpto 10A
AC CurrentUpto 10A
ResistanceUpto 60MOhm
CapacitanceUpto 9.999mF
Frequency99.99Hz ~ 10.00MHz
Measuring CategoryCAT III 600V, CAT II 1000V
Power Supply2x 1.5V AAA Batteries
Battery Life200 Hours Typical
Dimensions (mm)142 x 68 x 36 mm
