UNI-T 3099 Count / 600A AC TRMS Digital Clamp Meter, UT200B+
Roll over the image to zoom in
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹1,906 (Incl. of all taxes)
₹1,615 + ₹291 GST (18%)
MRP was MRP ₹1,900
Save 15%
7 Business Days
1
–
Download Product LeafletNot available
Download UNI-T CatalogueNot available
Download UNI-T CatalogueNot available
Highlights
UT200B+ AC current digital clamp meters are suitable for daily repair and maintenance of household equipment, mainly used by electricians; Featured minimum 3A AC current measurement, True RMS, LIVE test, and Audible/Visual alarm functions, they are good tools for home users or DIY enthusiasts.
Features:
- True RMS
- AC/DC 600V voltage measurement
- AC 600A current measurement
- Continuity / resistance / capacitance / diode / high voltage frequency measurement
- LIVE function & Flashlight
- Continuity and Diode, two-in-one
- Auto range
- High voltage warning
- Hold/Backlight
Technical Data:
| Specification | Range | Accuracy |
| Current (ACA) | 3.000A | ±(4%+10) |
| 30.00A | ±(4%+5) | |
| 600.0A | ±(4%+5) | |
| Voltage (ACV) | 3.000V ~ 600V | ±(1.2%+5) |
| Frequency(Hz) | 10H - 10kHz | ±(1.0%+5) |
| Voltage (DCV) | 3.000V ~ 300.0V | ±(1.0%+5) |
| 300.0V ~ 600V | ±(1.0%+3) | |
| Resistance | 300.0Ω ~ 300.0kΩ | ±(1.0%+5) |
| 300.0kΩ ~ 3.000MΩ | ±(2.0%+5) | |
| Capacitance | 30.00nF~300.0nF | ±(4%+10) |
| 3.000μF~300.0μF | ±(4%+5) | |
| 1.000mF | ±(5%+10) |
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Jaw Size | 28 mm |
|---|---|
| Display Count | 3099 |
| Overvoltage Category | CAT III 600V |
