Metravi 3-3/4 Digit / 600A Digital Auto-Ranging TRMS AC/DC Clamp Meter, DT-425T

Metravi DT-425T is a handheld auto-ranging clamp meter having 4,000 counts 3 3/4 digit backlit LCD display. The circuit design of the instrument uses the large scale integrated circuit S/D analog digital converter as core, with the full-range over-load protection circuit and a unique appearance design, makes it a dedicated ‘Must-Have’ instrument. It is used to measure AC/DC Voltage, AC Current, DC Current, Resistance, Diode, Circuit on-off, Capacitance, Temperature, Frequency and Duty cycle, and it is also equipped with functions as data-hold, maximum/minimum data measurement, relative value measurement, flashlight, NCV, under voltage display and Auto OFF.

3-3/4 Digits 3999 Counts Backlit LCD, T-RMS AC/DC Clamp meter, Confirms to CAT-III 600V, Data Hold, MAX/MIN, Relative, In-Built Flash Light, Overload Protection, 30mm Clamp Jaw Dia, Auto Power Off, AC T-RMS / DC Current 600A, AC T-RMS / DC Voltage 600V, Resistance, Capacitance, Temperature, Frequency, Non-contact Voltage Detector, Diode and Continuity Test.

Safety:

The instrument is designed and produced in strict accordance with IEC/EN 61010-1,1EC/EN 61010-2-032 and IEC/EN 61010-2-033, safety standards, and complies with the safety standard of double insulation, over-voltage CAT Ill 600V and pollution level 2. Please observe the following operation instruction, otherwise, the instrument provided protection is likely to be damaged.

Conforms to UL STD. 61010-1, 61010-2-032, 61010-2-033; Certified to CSA STD. C22.2 NO. 61010-1, IEC STD. 61010-2-032, IEC STD. 61010-2-033


• Hold : Freezes the displayed data.
• Max / Min : Records the maximum and minimum values displayed
• Rel : Helps to pertorun Relative measurement
• Flight : Switches the flash light ON to access dark areas.

Environmental Limitations:

• Working environment : Indoor use.
• Maximum altitude : 2,000m.
• Safety regulations : IEC/EN 61010-1; IEC/EN 61010-2-032; IEC/EN 61010-2-033.
• CAT Ill 600V; Pollution grade : 2
• Operating temperature and humidity : 0°C - 30°C (not larger than 80% RH), 30°C - 40°C (not larger than 75% RH), 40°C - 50°C (not larger than 45% RH).
• Storage temperature and humidity : -20°C -+ 60°C (not larger than 80% RH).

Electrical Specifications:

• Accuracy : ± (% reading + word count), calibration period is a year
• Ambient temperature : 23°C ± 5°C.
• Ambient humidity : ≤ 75%RH.
• Temperature coefficient : 0.1 x(accuracy)/°C.

Features:

• 3-3/4 Digits 3999 Counts Backlit LCD Display
• Built-in Flash light to access dark Areas
• Non Contact Voltage Detector to show the presence of Voltage
• Sleek Ergonomic Design
• Confirms to IEC/EN 61010-1, IEC/EN 61010-2-032 & IEC/EN 61010-2-033
• Confirms to UL, CAT-III 600V
• Data Hold to Freeze Displayed Data
• MAX-MIN record function
• Relative measuring facility
• Flashlight for working in dark areas
• Non-contact Voltage Detection
• Data Hold
• Max/Min/Avg/Dif : Max/Min
• Low Battery Indication
• 30mm Jaw Dia
• Overload indication
• 600V AC/DC Protection in all ranges
• Auto Power Off

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
