UNI-T 1200 Ohm / 4 Digit Clamp On Earth Resistance Tester, UT278A+
Roll over the image to zoom in
Key Features
- Product Type: Earth/Ground Resistance Tester
- Weight: 1.18 kg
- Resistance Range: 0.01 - 1200 Ohm
- Leakage Current (A): 0 mA - 20A
- Display Digits: 4 Digits
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹36,108 (Incl. of all taxes)
₹30,600 + ₹5,508 GST (18%)
MRP was MRP ₹36,000
Save 15%
7 Business Days
1
–
Download Product LeafletNot available
Download UNI-T CatalogueNot available
Download UNI-T CatalogueNot available
Highlights
UT278A+ series can quickly and safely measure the grounding system without disconnecting circuit ground lines or the need of auxiliary electrodes. It can measure resistance from 0.01Ω with a resolution of 0.001Ω. These clamps’ double insulation design makes them durable tools for outdoor work and effective in blocking interference from the environment.
Features:
- Auto range
- Data hold
- Data recall
- LCD backlight
- Resistance limit alarm
- Low battery indication
- Auto calibration
- Visual & audible alarm
- Auto power off
- Jamming signal recognition
- Over-range display
Technical Data:
| Specifications | Range | Accuracy |
| Earth Ground Resistance (Ω) | 0.01~0.099Ω | ±(1%+0.01) |
| 0.1~0.99Ω | ±(1%+0.01) | |
| 1~49.9Ω | ±(1%+0.1) | |
| 50~99.5Ω | ±(1.5%+0.5) | |
| 100~199Ω | ±(2%+1) | |
| 200~395Ω | ±(5%+5) | |
| 400~590Ω | ±(10%+10) | |
| 600~800Ω | ±(20%+20) | |
| 800~1200Ω | ±(25%+30) | |
| Leakage current (A) | 0mA~9mA | ±(2.5%+1mA) |
| 10mA~99mA | ±(2.5%+5mA) | |
| 100mA~299mA | ±(2.5%+10mA) | |
| 0.3A~2.99A | ±(2.5%+0.1A) | |
| 3A~9.9A | ±(2.5%+0.3A) | |
| 10A~20A | ±(2.5%+0.5A) |
Package Content:
- 1x Clamp on Earth/Ground Resistance Tester
- 4x 1.5V batteries (LR6)
- Test ring
- English manual
- Gift box
- tool box
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Resistance Range | 0.01 - 1200 Ohm |
|---|---|
| Leakage Current (A) | 0 mA - 20A |
| Display Digits | 4 Digits |
| Jaw Opening (mm) | 32 mm |
| Data Storage | 300 |
| Display Type | EBTN LCD Display |
| Display Size | 47 x 28.5 mm |
| Power Supply | 4x 1.5V battery (LR6) |
| Certificates | CE, UKCA |
| Dimensions (mm) | 285 x 85 x 56 mm |
