Metravi 3-3/4 Digit / 0 – 400mV Digital AC/DC Leakage Current Clamp Meter, DT-4672
Roll over the image to zoom in
Key Features
- Product Type: Leakage Testers
- Weight: 0.2 kg
- DC Voltage Range: 0 – 400mV / 4V / 40V / 400V / 600V
- DC Current Range: 0–4A/80A
- Capacitance Range: 0–40nF/400nF/4uF/40uF/100uF
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹8,449 (Incl. of all taxes)
₹7,160 + ₹1,289 GST (18%)
MRP was MRP ₹10,530
Save 32%
5 Business Days
1
90303100
Download Product LeafletNot available
Download Metravi CatalogueNot available
Download Metravi CatalogueNot available
Highlights
AC/DC Leakage Current Clamp Meter 3-3/4 Digits, LCD, Data Hold, 23mm Jaw Size, AC/DC Voltage, AC/DC Leakage Current measurement, Capacitance, Resistance, Frequency, Duty Cycle, Diode & Continuity Test.
Safety:
For indoor use and in accordance with Overvoltage Category II, Pollution Degree 2. Category II includes local level, appliance, portable equipment, etc., with transient overvoltages less than overvoltage Cat III
Features:
- Data Hold Function
- Auto Power Off
- Diode & Continuity test
- High Precision AC/DC Low Current Measurement
- Low battery and Overload Indication
- Provides Analogue Output for Recording function.
- Confirms to CE, CAT-III 600V
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Display | Backlit LCD |
|---|---|
| Colour | Yellow-Black |
| Duty Cycle Range | 0.5% to 99% |
| Jaw Dia | 23 mm |
| Sampling Time | 2 times/sec |
| Power Source | Battery Operated |
| Battery Type | Alkaline |
| Battery Size | AAA |
| DC Voltage Range | 0 – 400mV / 4V / 40V / 400V / 600V |
| AC Voltage Range | 0 – 400mV / 4V / 40V / 400V / 600V |
| DC Current Range | 0–4A/80A |
| AC Current Range | 0–4A/80A |
| Resistance Range | 0 – 400 / 4k / 40k / 400k / 4M / 40M Ohms |
| Capacitance Range | 0–40nF/400nF/4uF/40uF/100uF |
| Frequency Range | 0–5Hz/50Hz/500Hz/5kHz/50kHz/500kHz/5MHz/10MHz |
| DC Voltage Accuracy | ±1% |
| AC Voltage Accuracy | ±1.0% |
| DC Current Accuracy | ±2.8% |
| AC Current Accuracy | ±3.0% |
| Resistance Accuracy | ±1.0% |
| Capacitance Accuracy | ±3.0% |
| Frequency Accuracy | ±1.2% |
| Certifications | CAT-III 600V, CE, IEC-61010-031 |
