Metravi 3-3/4 Digits / 1000V Digital Multimeter, 801

Shop all Metravi

SKU: ME.EL.MU.00073

Model: 801

Roll over the image to zoom in


Key Features

  • Product Type: Multimeter
  • Weight: 375 g
  • DC Voltage Resolution: 0.1mV to 1V
  • DC Current Resolution: 10uA to 10mA
  • Resistance Resolution: 0.1 to 100k Ohms
See all product information

ToolBuy Benefits

₹2,544 (Incl. of all taxes)

₹2,156 + ₹388 GST (18%)

MRP was MRP ₹3,171

Save 32%


Out of Stock

5 Business Days

1

90308990

Download Product LeafletNot available
Download Metravi CatalogueNot available

Highlights

3-3/4 Digits, LCD, Peak Hold, AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Frequency, Logic Test, Diode & Continuity Test. 500V DC/AC Protection in Resistance, Capacitance, Frequency, Logic, Diode & Continuity Test.

Features:

  • Peak Hold to freeze the peak value
  • Auto Power Off
  • Low Battery Indication
  • Automatic Zero Facility
  • Display: 3-¾ Digits 3999 counts LCD
  • DC Voltage: 0-400mV/4V/40V/400V/1000V
  • Accuracy: ± 0.5%
  • AC Voltage: 0 – 400mV/4V/40V/400V/750V
  • Accuracy: ± 1.0%
  • DC Current: 0 – 40mA/400mA/20A
  • Accuracy: ± 1.0%
  • AC Current: 0 – 40mA/400mA/20A
  • Accuracy: ± 1.5%
  • Resistance: 0 – 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ/400MΩ
  • Accuracy: ± 0.8%
  • Capacitance: 0 – 4nF/40nF/400nF/4uF/40uF
  • Accuracy: ± 5%
  • Frequency: 0 – 4kHz/40KHz/400KHz/4000kHz
  • Accuracy: ± 0.1%
  • Logic Test, Diode Test, and Audible Continuity Test Facility
  • Has Overload Protection of 500V DC / AC RMS in Resistance, Capacitance, Logic Test, Frequency, Diode Test and Audible Continuity Test Ranges.

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

Technical specifications for Metravi 3-3/4 Digits / 1000V Digital Multimeter, 801
DisplayBacklit LCD
ColourYellow-Black
PolarityAutomatic
Sampling Time2.5 times/sec.
Power SourceBattery Operated
Battery TypeAlkaline
Battery Size9V
No of Batteries1
DC Voltage Resolution0.1mV to 1V
AC Voltage Resolution0.1mV to 1V
DC Current Resolution10uA to 10mA
AC Current Resolution10μA to 10mA
Resistance Resolution0.1 to 100k Ohms
Capacitance Resolution1pF to 10nF
CertificationsCAT III 1000V, CAT IV 600V, EN-61010-1
