UNI-T 999 Count / 600V Digital RCD (ELCB) Tester, UT582+
Roll over the image to zoom in
Key Features
- Product Type: Insulation Testers
- Weight: 400 g
- Display Count: 999
- Voltage Range: 30 ~ 600V
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹11,133 (Incl. of all taxes)
₹9,435 + ₹1,698 GST (18%)
MRP was MRP ₹11,100
Save 15%
7 Business Days
1
–
Download Product LeafletNot available
Download UNI-T CatalogueNot available
Download UNI-T CatalogueNot available
Highlights
UT582+ is mainly used to detect whether the RCD in the circuit can be triggered normally. It is only suitable for single-phase circuits with the supply voltage range of 195V~253V. Its voltage measurement range is 30V~600V, 45Hz~65Hz.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- Power Off Gear: Simply turn off the device when not in use.
- LCD backlight: Improves visibility in different lighting conditions.
- Data retention: Freezes and retains the displayed data for convenience.
- AUTO RAMP: Automatic ramp function for efficient operation.
- Disconnect buzzer: Acoustic alarm when the device is disconnected.
- Over-range indicator (OL): Indicates when the measurement exceeds the range.
- Protective fuses: Equipped with fuses to protect against overloads.
- Misoperation buzzer: Acoustic warning in case of incorrect operation.
- Power off buzzer: Acoustic alarm when the device is switched off.
- Full icon display: Comprehensive icon display for easy interpretation of information
Technical Data:
| Specifications | Range | UT582+ | ||
| RCD measurement | Range setting | Rated operating current | Trip time | |
| X 1/2 | 10mA / 20mA / 30mA / 100mA / 300mA / 500mA | 2000ms | -10%~0% | |
| X 1 | 10mA / 20mA / 30mA / 100mA / 300mA | 1000ms | 0%~10% | |
| 500mA | 300ms | 0%~10% | ||
| X 5 | 10mA / 20mA / 30mA | 40ms | 0%~10% | |
| AUTO RAMP | 10mA / 20mA / 30mA / 100mA / 300mA / 500mA | 300ms | -10%~10% | |
| Trip time accuracy | ±(2%+2) | |||
| Operating voltage (Freq.) | 195V ~ 253V |
Package Content:
- 1x Digital RCD (ELCB) Tester
- Test line
- Carrying Bag
- Elastic Strap
- Gift box
- English manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Display Count | 999 |
|---|---|
| Voltage Range | 30 ~ 600V |
| Voltage Frequency | 45Hz ~ 65Hz |
| Voltage Resolution | 1V |
| Voltage Accuracy | ±(3%+3) |
| Low Battery Indication | <7.2V |
| Phase Angle Selection | 0° & 180° |
| Connections Check | Simultaneously Test The Trip Time & Trip Current |
| Compliance Standard | IEC 61010-1, IEC 61010-2-030, IEC 61010-2-033, IEC 61557-1:2007;IEC 61557-6:2007, EN61326-1, EN61326-2-2 |
| Lead Sequence Check | LCD |
| Power Supply | 6x 1.5V Batteries (LR6) |
| Display Size | 71 x 34 mm |
| Product Color | Red & Grey |
| Dimensions (mm) | 160 x 100 x 71 mm |
